Honeywell MC-TAMT03 51309223-175 LLMux Analog Input TC with compression terminals Ready For Ship, China Honeywell MC-TAMT03 51309223-175 LLMux Analog Input TC with compression terminals Ready For Ship Manufacturers, Suppliers, Factory

Overview

Brand Name:	Honeywell
Model Number:	MC-TAMT03 51309223-175
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Model	MC-TAMT03 51309223-175
Type	LLMUX2 Thermocouple FTA
Input Channels	16 isolated channels
Input Type	Thermocouple (TC)
Signal Bandwidth	0–4.7 Hz
Scan Rate	1 second fixed
Operating Temp	0 to 50°C
Storage Temp	-40 to 80°C
Humidity	10–90% non-condensing
Power Dissipation	~2.25 W max
Dimension	Refer to system enclosure spec
Weight	Refer to installation datasheet

Description

The MC-TAMT03 51309223-175 is part of the Honeywell LLMUX2 series Field Termination Assembly designed for high-accuracy thermocouple signal acquisition in distributed process control systems. It supports reliable analog input processing for temperature monitoring applications in demanding industrial environments.

Built with enhanced LLMUX2 architecture, the MC-TAMT03 51309223-175 provides improved signal stability, fast open thermocouple detection, and superior channel isolation. It is engineered to work seamlessly with related models such as MC-TAMT02 and MC-TAMT12, supporting both local and remote cold junction reference configurations.

With conformal coating protection available across the LLMUX2 family, including the MC-TAMT03 51309223-175, the unit is suitable for corrosive and humidity-prone environments, ensuring long-term reliability in process automation systems.

Applications

Power plants: Generator monitoring and relay protection.
Substations: Bus protection, switchgear signal acquisition.
Chemical plants: Process automation and safe signal monitoring.
Steel mills: High-temperature control and EMI-heavy environments.
Machinery manufacturing: Robotics, packaging, and automated production lines.

Features

16 fully isolated input channels
Fast thermocouple fault detection
Enhanced environmental resistance via conformal coating support
High noise immunity and signal stability
Modular LLMUX2 architecture compatibility

Functions

Temperature signal acquisition and conversion
Process control data transmission to PM systems
Fault detection for open thermocouples
Industrial-grade signal conditioning and isolation

(≈120 words total technical section)

FAQ

Q1: What is MC-TAMT03 51309223-175 used for?
A1: It is used for thermocouple-based temperature signal acquisition in industrial process control systems.

Q2: Does MC-TAMT03 support channel isolation?
A2: Yes, it provides fully isolated channels for stable and interference-free measurement.

Q3: Can it operate in harsh environments?
A3: Yes, it supports conformal coating protection for humid and corrosive conditions.

Q4: Is MC-TAMT03 compatible with other LLMUX2 modules?
A4: Yes, it works with related models such as MC-TAMT02 and MC-TAMT12.

Q5: What industries commonly use this FTA?
A5: It is widely used in power plants, substations, chemical plants, steel mills, and manufacturing systems.

Spares

Number	Describe
MU-TAMR03	LLMux RTD FTA
MC-TAMR03	LLMux RTD FTA – Conformally Coated
MU-TAMT03	LLMux TC FTA
MC-TAMT03	LLMux TC FTA – Conformally Coated
MU-TAMT13	LLMux TC FTA with Remote CJR
MC-TAMT13	LLMux TC FTA with Remote CJR – Conformally Coated
MU-TLPA02	Power Adapter
MC-TLPA02	Power Adapter – Conformally Coated
MU-PLAM02	LLMux IOP
MC-PLAM02	LLMux IOP – Conformally Coated
