Honeywell MC-TDOY22 51204162-175 24 Vdc Isolated Digital Output with compression term In stock, China Honeywell MC-TDOY22 51204162-175 24 Vdc Isolated Digital Output with compression term In stock Manufacturers, Suppliers, Factory

Overview

Brand Name:	Honeywell
Model Number:	MC-TDOY22 51204162-175
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Item	Description
Model	MC-TDOY22
Part Number	51204162-175
Output Type	Isolated Digital Relay Output
Rated Voltage	24 Vdc
Channel Type	Multi-channel relay output
Terminal Type	Compression terminal
Electrical Isolation	Galvanically isolated design
Operating Temperature	-20°C to +70°C
Dimension	Approx. 160 × 100 × 60 mm
Weight	Approx. 0.6 kg
Mounting	Rack-mounted FTA system compatible

Description

TheMC-TDOY22 51204162-175is a high-reliability isolated digital output relay module designed for industrial process control systems requiring stable switching performance. It delivers 24 Vdc isolated output capability, ensuring safe signal separation and enhanced system protection in demanding automation environments.

TheMC-TDOY22series is engineered for seamless integration with compatible Honeywell I/O architectures, supporting robust relay-based control for field devices such as alarms, actuators, and interlocking systems. Related models such asMC-TDOY23 80366189-175andMC-TDOY63 80366185-175expand configuration flexibility across different terminal styles and voltage requirements.

Built with industrial-grade isolation and compression terminal design, theMC-TDOY22ensures reliable operation under electrical noise, vibration, and continuous duty cycles, making it suitable for critical automation infrastructure.

Applications

Power plants: Used for generator set status monitoring and relay protection
Substations: Enables bus differential control and switchyard signal acquisition
Chemical plants: Supports automation control and intrinsically safe monitoring
Steel mills: Ensures stable control under high temperature and EMI conditions
Machinery manufacturing: Used in automated production lines and robotic systems

Features

High isolation relay output design
Stable 24 Vdc switching performance
Industrial-grade compression terminal connection
Strong anti-interference capability
Compatible with distributed control systems

Functions

Digital signal output control
Relay switching for field devices
Electrical isolation protection
System-level process interlocking
Signal transmission between controller and actuators

FAQ

Q1: What is the main function of MC-TDOY22?
A1: It provides isolated relay-based digital output for industrial automation control systems.

Q2: Is MC-TDOY22 suitable for harsh environments?
A2: Yes, it is designed to operate reliably in high noise and industrial conditions.

Q3: What voltage does MC-TDOY22 support?
A3: It supports 24 Vdc isolated output operation.

Q4: What type of terminals does it use?
A4: It uses compression-type terminals for secure field wiring connections.

Q5: Can MC-TDOY22 be used in process plants?
A5: Yes, it is widely used in power plants, chemical plants, and manufacturing automation systems.

Spares

Number	Describe
MC-TDIA62	51304431-250 / 51304431-275 240 Vac Digital Input with fixed-screw terminals
MC-TDID12	51304441-150 / 51304441-175 24 Vdc Digital Input with compression terminals
MC-TDID52	51304441-250 / 51304441-275 24 Vdc Digital Input with fixed-screw terminals
MC-TDID72	51303928-150 24 Vdc Digital Input with removable-screw terminals
MC-TDIY22	80366180-150 / 80366180-175 24 Vdc Digital Input with compression terminals
MC-TDIY62	80366180-250 / 80366180-275 24 Vdc Digital Input with fixed-screw terminals
MC-TDOA13	51304648-150 / 51304648-175 120/240 Vac Solid-State Digital Output with compression terminals
MC-TDOA53	51304648-250 / 51304648-275 120/240 Vac Solid-State Digital Output with screw terminals
MC-TDOD13	51304650-150 3-30 Vdc Digital Output with compression terminals
MC-TDOD14	51309153-175 3-30 Vdc Digital Output with compression terminals
MC-TDOD22	51304428-150 31-200 Vdc Digital Output with compression terminals
MC-TDOD23	51309154-175 31-200 Vdc Digital Output with compression terminals
MC-TDOD53	51304650-250 3-30 Vdc Digital Output with screw terminals
MC-TDOD54	51309153-275 3-30 Vdc Digital Output with screw terminals
MC-TDOD62	51304428-250 31-200 Vdc Digital Output with screw terminals
MC-TDOD63	51309154-275 31-200 Vdc Digital Output with screw terminals
MC-TDON12	51304446-150 24 Vdc Nonisolated Digital Output with compression terminals
MC-TDON52	51304446-250 24 Vdc Nonisolated Digital Output with screw terminals
MC-TDOY22	80366183-150 / 80366183-175 24 Vdc Isolated Digital Output with compression terminals
MC-TDOY62	80364013-150 / 80364013-175 24 Vdc Isolated Digital Output with screw terminals
MC-TDOR12	51304443-150 / 51309148-175 120 Vac/125 Vdc Relay Digital Output with compression terminals
MC-TDOR52	51304443-250 / 51309148-275 120 Vac/125 Vdc Relay Digital Output with screw terminals
MC-TDOR22	51304427-150 / 51309150-175 240 Vac/125 Vdc Relay Digital Output with compression terminals
MC-TDOR62	51304427-250 / 51309150-275 240 Vac/125 Vdc Relay Digital Output with screw terminals
