Honeywell TC-HAO081 Analog Output Current/Voltage Module Ready For Ship, China Honeywell TC-HAO081 Analog Output Current/Voltage Module Ready For Ship Manufacturers, Suppliers, Factory

Overview

Brand Name:	Honeywell
Model Number:	TC-HAO081
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Item	Details
Model	TC-HAO081
Type	8-channel Analog Output Module
Communication	HART protocol enabled
System Platform	HAZ-RTP motherboard system
Connector Type	25-pin DSUB female system connector
Terminal Interface	6-pin FSY cable tree connection
Power Supply	Redundant DC power input
Mounting Type	DIN rail mounted motherboard system
Operating Temp	-20°C to +60°C
Storage Temp	-40°C to +85°C
Dimension	165x150x150 mm
Weight	1.3 kg
Housing Material	Industrial metal base plate
Protection Level	Industrial EMI-resistant design

Description

TheTC-HAO081analog output module with HART capability is designed for high-precision signal control in industrial automation systems. It is commonly used within Pepperl+Fuchs HAZ-RTP motherboard platforms, supporting stable integration with Honeywell 1756 rack I/O architectures for process control applications.

The system architecture includes compatible models such asFSY-L456-98837,KFD0-LC1-8M-99143, and theHAZ-RTP-HAO081-132002motherboard, which together enable reliable analog output distribution with enhanced diagnostic and communication performance.

Built for demanding industrial environments, theTC-HAO081supports multi-channel HART-enabled output control, redundant power configuration, and modular FSY cable tree connectivity, ensuring safe, scalable, and efficient signal transmission in modern automation systems.

Applications

Power plants: Generator set monitoring and relay protection
Substations: Bus differential control and signal acquisition
Chemical plants: Process automation and intrinsic safety monitoring
Steel mills: High-temperature control and EMI-heavy environments
Machinery manufacturing: Automated production and robotics control

Features

8-channel analog output with HART communication support
Integrated with HAZ-RTP motherboard for stable system architecture
Redundant power supply design enhances operational reliability
FSY cable tree connection ensures flexible wiring configuration
Industrial-grade PCB and DIN rail mounting for harsh environments

Functions

Provides precise analog signal output for process control systems
Enables HART-based field device diagnostics and monitoring
Distributes control signals across multi-module automation networks
Supports integration with Honeywell-compatible rack I/O systems
Ensures stable performance in continuous industrial operations

FAQ

Q1: What is the main function of TC-HAO081?
A1: It provides 8-channel HART-enabled analog output for industrial process control systems.

Q2: Is TC-HAO081 compatible with Honeywell systems?
A2: Yes, it integrates with Honeywell 1756 rack I/O via HAZ-RTP motherboard platforms.

Q3: Does it support redundant power supply?
A3: Yes, the system is designed with redundant power input for higher reliability.

Q4: What type of communication does it support?
A4: It supports HART protocol for advanced diagnostics and field communication.

Q5: Where is TC-HAO081 commonly used?
A5: It is used in power plants, substations, chemical plants, and heavy industrial automation systems.

Spares

Number	Describe
TC/TK-IAH061	6-channel analog input module with HAZ-RTP-IAH061 motherboard, D-SUB 25-pin connector, dual HART interface, compact 165×150×150 mm design for Honeywell 1756 Rack I/O integration
TC/TK-IAH161	16-channel analog input system using HAZ-RTP-IAH161 / IAH161H / IAH161S motherboards, up to 32-channel capability, D-SUB 37-pin connector, industrial 325×150×150 mm chassis
TC/TK-OAV081	8-channel analog output module with HAZ-RTP-OAV081 motherboard, D-SUB 25-pin interface, HART-enabled communication, 165×150×150 mm compact industrial design
TC/TK-HAO081	8-channel HART analog output system using HAZ-RTP-HAO081 motherboard, galvanic isolation, dual HART 26-pin interface, stable 165×150×150 mm structure
TC/TK-HAI081	8-channel HART-enabled analog input module with HAZ-RTP-HAI081 motherboard, D-SUB 25-pin connector, dual HART interface, 165×150×150 mm enclosure
TC/TK-IDX161	16-channel digital input module using HAZ-RTP-IDX161 motherboard, dual-channel KFD2-SR2-Ex2.2S interface, D-SUB 37-pin connector, 165×150×150 mm design
TC/TK-IDD321	32-channel digital input system with HAZ-RTP-IDD321 motherboard, 4-module architecture, D-SUB 37-pin connector, high-density 165×150×150 mm platform
TC/TK-ODX121	16-channel digital output module using HAZ-RTP-ODX121 motherboard, dual-channel relay interface, D-SUB 37-pin connector, industrial 165×150×150 mm housing
TC/TK-ODD321	32-channel digital output system with HAZ-RTP-ODD321 motherboard, dual-channel isolated design, D-SUB 37-pin connector, scalable 165×150×150 mm structure
