Product Name:32-Point Discrete Output Module
Brand Name:HONEYWELL
Model Number:TK-ODD321
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Honeywell |
Model Number: |
TK-ODD321 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Description |
Value |
|
Model |
TK-ODD321 |
|
Type |
24 VDC, 32-Point Discrete Output Module |
|
Output Voltage Range |
10-31.2 VDC @ 50°C (Linear derating) 10-28 VDC @ 60° |
|
Surge Current |
1A for 10ms each, repeatable every 2s @ 60C |
|
Flash On Time |
100 msec target, 150 msec max |
|
Off-State Leakage Current (Maximum) |
0.5 mA per point (1 mA per point IEC 1131-2 for 0.25 A output) |
|
Configurable Fault States per Point |
Hold Last State, ON or OFF (OFF is the default) |
|
Power Dissipation |
6.1 W |
|
Dimension |
3.5x14.1x14.5cm |
|
Weight |
0.22kg |
The TK-ODD321 is a high-density 24 VDC discrete output module developed for Honeywell Experion Series-A control systems. Designed to deliver dependable switching performance, it provides 32 output points for efficient control of valves, relays, lamps, and other field devices in industrial automation processes.
As a conformal-coated version of the TC-ODD321, the TK-ODD321 offers enhanced resistance to moisture, dust, and corrosive atmospheres. It can be integrated with related modules such as TK-IDD321, TK-ODJ161, and TK-PRS021 to create flexible and scalable plant control architectures.
With fast response time, stable load handling, and strong chassis compatibility, the TK-ODD321 is widely applied in power plants, chemical facilities, steel production lines, and manufacturing systems requiring reliable 24 VDC output control.
Q1: What is the TK-ODD321 used for?
A1: The TK-ODD321 is used to provide 32 channels of 24 VDC discrete output control.
Q2: How many outputs does the TK-ODD321 have?
A2: It features 32 output points arranged in common groups.
Q3: What systems support the TK-ODD321?
A3: It is designed for Honeywell Experion Series-A chassis platforms.
Q4: Is the TK-ODD321 suitable for harsh environments?
A4: Yes, its conformal coating helps resist dust, moisture, and corrosion.
Q5: What devices can the TK-ODD321 control?
A5: It can switch relays, valves, solenoids, indicators, and other 24 VDC loads.
