ICS TRIPLEX T8850 40 Channel Analog or Digital Output FTA

ICS TRIPLEX T8850 40 Channel Analog or Digital Output FTA

Product Name: 40 Channel Analog or Digital Output FTA

Brand Name: ICS TRIPLEX

Model Number: T8850

Place of Origin: USA

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

ics triplex t8850 40 channel analog or digital output fta-1

Overview
Specifications
Commercial Terms
Description
Features
FAQ
Other Brand
Why Choose Us
Recommended Products

Contact Info

Sales	Email	Phone/Whatsapp
Jim Pei	[email protected]	+86 18020776782

Specifications

Product Name	ICS TRIPLEX T8850 40 Channel Analog or Digital Output FTA
Manufacturer	ICS TRIPLEX
Product Type	40 Channel Analog or Digital Output FTA
Part Number	T8850
Weight	0.62kg
Estimated shipping dimensions	30.2x12.5x6.2cm
Place of shipment	Xiamen, China
Country of origin	USA
Product Family	Trusted
Product Type	Field Termination Assembly (FTA)
Number of Channels	40
Channel Configuration	5 Groups of 8 Identical Channels
Digital Output Signal	24 VDC
Analog Output Signal	0–20 mA
Compatible Digital Output Modules	T8451 / T8461
Compatible Analog Output Module	T8480
Field Connections	0 V and 24 V via Terminal Strips
Return Voltage	0 V
Return Connection	Bus Bar to FTA via 10-Way Terminal Block
24 VDC Power Source	T8290 Output Power Distribution Unit
Output Module Connection	96-Way Socket JDH2

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Description

The ICS Triplex T8850 is a 40-channel Analog or Digital Output Field Termination Assembly (FTA) designed for the Trusted safety and control system platform. It provides 40 output channels arranged in five groups of eight and supports both 24 VDC digital outputs and 0–20 mA analog outputs, depending on the connected output module. Compatible with T8451/T8461 digital output modules and the T8480 analog output module, the FTA provides an organized interface between Trusted output modules and field devices. Its high channel density and flexible signal support make it well suited for process control, emergency shutdown, plant automation, and other high-availability industrial applications.

Features

Provides 40 output channels in a single FTA, supporting high-density field termination for Trusted safety and control systems.
Channels are organized into five groups of eight, simplifying field wiring, signal organization, and system maintenance.
Supports both 24 VDC digital output and 0–20 mA analog output applications, providing flexibility for different field control requirements.
Compatible with Trusted T8451 and T8461 digital output modules for integration with discrete field devices.
Supports the Trusted T8480 analog output module for control of compatible analog field instrumentation.
Flexible architecture allows the same FTA platform to serve different output applications depending on the installed Trusted module.
Terminal-strip connections provide convenient access to 0 V and 24 VDC field wiring for straightforward installation.
Dedicated bus-bar return arrangement helps organize common 0 V connections and simplify control cabinet wiring.
Designed to receive 24 VDC field power from the T8290 Output Power Distribution Unit for coordinated integration within Trusted system architectures.
96-way output-module connection provides an organized interface between the FTA and compatible Trusted output modules.

FAQ

Q1: What is the ICS Triplex T8850?
The T8850 is a 40-channel Field Termination Assembly designed to connect compatible Trusted analog or digital output modules with industrial field devices.

Q2: How many output channels does the T8850 provide?
It provides 40 channels arranged in five groups of eight identical channels.

Q3: Does the T8850 support both analog and digital outputs?
Yes. It can support 24 VDC digital outputs or 0–20 mA analog outputs depending on the compatible Trusted output module used.

Q4: Which digital output modules are compatible with the T8850?
The T8850 is compatible with the Trusted T8451 and T8461 digital output modules.

Q5: Which analog output module can be used with the T8850?
It supports the Trusted T8480 analog output module for 0–20 mA analog output applications.

Q6: How is field power supplied to the T8850?
The T8850 is designed to receive 24 VDC field power from the T8290 Output Power Distribution Unit within a compatible Trusted system.
