Product Name: VME Profibus Network Interface Card
Brand Name: Molex Woodhead
Model Number: SST-PB3-VME-2
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales |
Phone/Whatsapp |
|
Jim Pei |
| Product Name | Molex Woodhead SST-PB3-VME-2 VME Profibus Network Interface Card |
| Manufacturer | Molex Woodhead |
| Product Type | VME Profibus Network Interface Card |
| Part Number | SST-PB3-VME-2 |
| Weight | 0.26kg |
| Estimated shipping dimensions | 2x17.8x26.1cm |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Number of Profibus Channels | 2 independent channels |
| Channel Architecture | Each channel is controlled by an independent CPU |
| VME Module Size | Double-height (6U) module |
| VME Compliance | VMEbus Spec VME64-compliant (VITA 1.1 1997) |
| Typical Current Draw | 1400 mA @ +5 V ±5% |
| Operating Temperature | 0°C to 50°C |
| Storage Temperature | -25°C to 70°C |
| Operating Humidity | 5% to 90%, non-condensing |
| Network Protocol / Physical Layer | RS485 |
| Network Isolation | 1000 V |
| Maximum Profibus Data Rate | 12 Mbps |
| Profibus Connector | 1 × standard DB9 female connector per channel |
| Profibus Power | 5 VDC supplied by each channel |
| VME Data Transfer | 16-bit transfers (VME D16) |
| VME Address Transfers | VME A24 standard address and VME A16 short I/O address |
| Memory Resource | 256K × 16-bit window per channel |
| Memory Location | Configurable anywhere in VME standard space |
| I/O Resource | 32-byte range per channel |
| Minimum Host Memory Window | 256K |
| Short I/O Access | 8-bit |
| Standard Address Access | 8-bit and 16-bit |
| Interrupt Levels | VMEbus interrupt lines 1 through 7, or disabled |
| Interrupt Type | ROAK (Release-on-Acknowledge) |
| DIP Switch | 10-position DIP switch |
| DIP Switch Functions | Short I/O address, access privilege, and interrupt level |
| Default Short I/O Address | 0x0000 for Channel A; Channel B begins at 0x0200 |
| Default Interrupt Setting | Disabled |
| Byte Ordering | Intel-style (Little Endian) |
| Serial Port Default Baud Rate | 115200 baud |
| Serial Port Format | No parity, 8 data bits, 1 stop bit |
| Serial Port Baud Range | 9600 to 115 Kbaud |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
The Molex Woodhead SST-PB3-VME-2 is a dual-channel VME Profibus Network Interface Card designed to provide high-performance Profibus connectivity for VME-based industrial control systems. It features two independent Profibus channels, each controlled by a dedicated CPU, with RS485 communication and data rates up to 12 Mbps. The 6U VME64-compliant module provides dedicated memory resources for each channel and supports configurable VME addressing and interrupt functions. Its independent channel architecture makes it suitable for industrial control, factory automation, process systems, test equipment, and legacy VME applications requiring reliable multi-network Profibus communication.
Compared with conventional single-channel Profibus interface cards, the Molex Woodhead SST-PB3-VME-2 provides dual independent communication channels, dedicated processing resources, high-speed Profibus connectivity, and flexible VME integration for demanding industrial applications.
