MTL Instruments 8103AI-TX / 8103-AI-TX 8-Channel Analog Input Module

MTL Instruments 8103AI-TX / 8103-AI-TX 8-Channel Analog Input Module

Product Name: 8-Channel Analog Input Module

Brand Name: MTL Instruments

Model Number: 8103AI-TX / 8103-AI-TX

Place of Origin: UK

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

mtl instruments 8103ai tx 8103 ai tx 8 channel analog input module-1

Overview
Product Parameters
Commercial Terms
Contact Us
Why Choose US
Major Business
Product Feature
FAQ
Recommended Products

Overview

The MTL Instruments 8103AI-TX 8-Channel Analog Input Module is a high-precision analog input module designed for reliable acquisition of process signals in industrial automation and process control systems. Featuring eight independent analog input channels, it accepts standard 4–20 mA signals from both 2-wire and 4-wire transmitters, delivering 16-bit resolution with ±0.1% of span accuracy for precise measurement. The module includes configurable filtering, user-defined alarm deadbands, line fault detection, and selectable failsafe modes to enhance system reliability. With an active lifecycle, low power consumption, and support for non-incendive field circuits, it is an ideal solution for monitoring process variables in demanding industrial environments.

Product Parameters

Product Name	MTL Instruments 8103AI-TX 8-Channel Analog Input Module
Manufacturer	Eaton MTL
Product Type	8-Channel Analog Input Module
Part Number	8103AI-TX
Weight	0.22kg
Estimated shipping dimensions	4.2x12.5x10.5cm
Place of shipment	Xiamen, China
Country of origin	UK
Lifecycle Status	Active
Number of Channels	8
Input Range	4 to 20 mA
Bussed Field Power	24 VDC ±10%; 300 mA (2-wire), 60 mA (4-wire)
Transmitter Type	2-wire or 4-wire
Full Signal Range	1–23 mA
Output Current	32 mA Max.
Failsafe Mode	Low, High or Hold Last Value
LED Indicators	Power, Fault, 8 × Channel Status
Alarms	Hi Hi, Hi, Lo, Lo Lo
Alarm Deadband	User-Defined
Line Fault Detection	Open (<0.5 mA); Short (>23.5 mA)
Resolution	16-bit Unsigned
Accuracy	±0.1% of Span
Repeatability	0.05% of Span
Response Time	27 ms Max.
Channel-to-Channel Isolation	No
Dead Zone	User-Defined; Zero Default
HART Data	N/A
Filtering	Configurable
Field Circuits	Non-incendive
System Power (12 V)	100 mA Typical, 150 mA Maximum
Module Key Code	A1

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Contact Us

Sales:	Email:	Whatsapp:
Jim Pei	[email protected]	+86 18020776782

Why Choose US

✔ Genuine Industrial Automation Products
✔ Strict Quality Inspection Before Shipment
✔ Competitive Prices & Flexible Quotations
✔ Large Inventory with Fast Global Shipping
✔ 12-Month Warranty on Eligible Products
✔ Professional Technical & After-Sales Support
✔ Inquiry Response Within 1 Hour
✔ Secure Packaging for International Shipping
✔ Trusted Supplier for PLC, DCS, HMI, and Industrial Control Systems

Major Business

ABB: Industrial robot parts of DSQC series,Bailey INFI90, DCS
Honeywell: 51/MU/MC/TC/CC ...
Triconex: 3008/3511/3625/3664/3721/3700A..
Bently Nevada: 3500/3300/330180-Cable..
Foxboro: FBM203/204/217/231, FCP240/270
Woodward: SPC valve position controller, PEAK15 digital controller
Siemens: 6DD/6DP/6ES5/6DR/6GK Series
Westinghouse Series: 1C/5X ...
General electric: IC693/IC697/IC695/DS200..
Schneider: 140 Series

Product Feature

Eight Analog Input Channels
Supports eight independent 4–20 mA input channels for efficient process signal acquisition.
Compatible with 2-Wire and 4-Wire Transmitters
Accepts signals from both loop-powered and externally powered field transmitters.
High Measurement Accuracy
Provides 16-bit resolution with ±0.1% of span accuracy and 0.05% repeatability for precise process monitoring.
Advanced Alarm Functions
Supports Hi Hi, Hi, Lo, and Lo Lo alarms with user-defined deadband settings for flexible process supervision.
Integrated Line Fault Detection
Detects open-circuit conditions below 0.5 mA and short-circuit conditions above 23.5 mA.
Configurable Signal Processing
Offers adjustable filtering and selectable failsafe modes including Low, High, or Hold Last Value.
Industrial Status Diagnostics
Includes dedicated LEDs for power, fault indication, and individual channel status monitoring.
Designed for Process Automation
Supports non-incendive field circuits and integrates seamlessly into industrial process control applications.

FAQ

---What is the 8103AI-TX used for?
8103AI-TX is used to acquire and process analog current signals from field transmitters in industrial automation and process control systems.

---How many input channels does the 8103AI-TX provide?
8103AI-TX provides eight independent analog input channels.

---What input signal range does the 8103AI-TX support?
8103AI-TX accepts standard 4–20 mA analog input signals with a full measurable range of 1–23 mA.

---What field power does the 8103AI-TX provide?
8103AI-TX provides a 24 VDC ±10% field supply capable of supporting 300 mA for 2-wire transmitters and 60 mA for 4-wire transmitters.

---What applications are suitable for the 8103AI-TX?
8103AI-TX is suitable for monitoring pressure, temperature, flow, level, and other 4–20 mA process signals in industrial automation systems.

---Why choose the 8103AI-TX for analog signal acquisition?
8103AI-TX combines eight high-accuracy analog input channels, 16-bit resolution, configurable alarms and filtering, line fault detection, flexible transmitter compatibility, and reliable industrial performance, making it an excellent solution for demanding process monitoring and control applications.
