Product Name: 'C' Programmable Application Development Module with Ethernet
Brand Name: ProSoft
Model Number: MVI56-ADMNET
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales |
Phone/Whatsapp |
|
Jim Pei |
| Product Name | ProSoft MVI56-ADMNET 'C' Programmable Application Development Module with Ethernet |
| Manufacturer | ProSoft |
| Product Type | C' Programmable Application Development Module with Ethernet |
| Part Number | MVI56-ADMNET |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Flash ROM Program Space | 896 KB |
| RAM Program and Data Space | 640 KB |
| Compact Flash | Up to 64 MB |
| Backplane Current Load | 800 mA @ 5 VDC; 3 mA @ 24 VDC |
| Operating Temperature | 32°F to 140°F (0°C to 60°C) |
| Storage Temperature | -40°F to 185°F (-40°C to 85°C) |
| Relative Humidity | 5% to 95%, non-condensing |
| Shock | 30 g operational; 50 g non-operational |
| Vibration | 5 g from 10 Hz to 150 Hz |
| LED Indicators | Module Status; Backplane Transfer Status; Application Status; Serial Activity |
| CFG Connector | RJ45, DB-9M with supplied cable |
| CFG Hardware Handshaking | None |
| Module Format | Single Slot, 1756 backplane compatible |
| Rack Installation | Local or remote rack |
| Serial Ports | 3 serial ports; 2 isolated field-interface ports and 1 debug/configuration port |
| Ethernet Interface | 10/100 Base-T |
| Ethernet Connector | RJ45 |
| Ethernet Indicators | Link and Activity LED indicators |
| Ethernet Electrical Isolation | 1500 V rms at 50–60 Hz for 60 s, per IEC 60950:1991 Section 5.3.2 |
| Ethernet Broadcast Storm Resiliency | ≤5000 ARP frames/s and ≤5 minutes duration |
| API | MVI56-ADMNET Ethernet Port API |
| API Programming Syntax | C programming language syntax |
| Development Operating System | General Software DOS 6-XL |
| Compatible Compiler | Digital Mars C++ V8.49 (included); Borland C++ V5.02 |
| ADM API Functions | Initialization; Debug Port; Database; Timer; Backplane; LED; Flash; Miscellaneous |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
The ProSoft MVI56-ADMNET is a programmable application development module with integrated Ethernet connectivity for Rockwell Automation ControlLogix systems. It provides a flexible C-programming platform with 896 KB Flash ROM, 640 KB RAM, CompactFlash support up to 64 MB, three serial ports, and a 10/100 Base-T Ethernet interface. Installed directly in a compatible 1756 backplane, the module allows developers to create custom communication, data-processing, and device-integration applications using the supplied APIs and C/C++ development tools. It is well suited for specialized industrial applications where standard communication modules or off-the-shelf protocols cannot fully meet system requirements.
Compared with fixed-function ControlLogix communication modules and conventional external gateways, the ProSoft MVI56-ADMNET provides greater flexibility for developing customized communication and data-processing solutions:
