ProSoft MVI56E-MNETR Modbus TCP/IP Client/Server enhanced communication module In stock

ProSoft MVI56E-MNETR Modbus TCP/IP Client/Server enhanced communication module In stock

Product Name:Modbus TCP/IP Client/Server enhanced communication module

Brand Name:ProSoft

Model Number:MVI56E-MNETR

Country of Origin:USA

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

server enhanced communication module in stock-1

Overview
Inquiry now
Specifications
Description
Applications
Control & Communication
Environment & Certification
FAQ
Spares
Recommended Products

Overview

Brand Name:	ProSoft
Model Number:	MVI56E-MNETR
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Inquiry now

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Product Model	MVI56E-MNETR, Modbus TCP/IP Client/Server communication module for ControlLogix systems, optimized for reduced I/O data transfer and remote rack integration
Communication Protocol	Modbus TCP/IP Client/Server, supports bidirectional industrial data exchange with Modbus-compatible devices
Ethernet Port	10/100 Mbps auto-sensing Ethernet port, supports configuration, diagnostics, and Modbus communication
Memory Capacity	Up to 5000 16-bit registers, configurable data mapping for flexible control applications
Power Consumption	800 mA @ 5 VDC, low-power industrial backplane operation for ControlLogix chassis
Operating Temperature	0°C to 60°C, suitable for standard industrial automation environments
Weight	Approx. 0.35–0.45 kg, compact design for single-slot ControlLogix installation
Dimension	Standard 1756 single-slot module size, designed for ControlLogix chassis integration

Description

The MVI56E-MNETR is a Modbus TCP/IP Client/Server enhanced communication module designed for Rockwell Automation ControlLogix systems. It enables seamless integration between ControlLogix PACs and Modbus-compatible devices, including PLCs, controllers, and industrial instrumentation, ensuring reliable cross-platform communication in automation networks.

The MVI56E-MNETR features a reduced I/O data block architecture, making it highly efficient for remote rack and bandwidth-limited ControlNet applications. It supports bidirectional Modbus TCP/IP data exchange with flexible configuration, improving system responsiveness and communication efficiency.

With built-in Ethernet diagnostics, web-based access, and configuration tools, the MVI56E-MNETR enhances system visibility and maintenance efficiency. It is widely used in industrial automation environments requiring stable, secure, and scalable Modbus communication integration.

Applications

Power plants: Used for generator monitoring, turbine control integration, and relay protection communication systems.
Substations: Enables bus differential protection, line monitoring, and SCADA signal acquisition across Modbus networks.
Chemical plants: Supports process automation integration and safe communication between PLC and field devices.
Steel mills: Provides stable control communication in high-temperature and high-EMI metallurgical environments.
Machinery manufacturing: Used in automated production lines, robotics systems, and packaging machine communication control.

Control & Communication

Dual Modbus TCP/IP Client/Server architecture enables flexible and reliable industrial data exchange between ControlLogix and Modbus devices
Reduced I/O data block design improves communication efficiency and is ideal for remote rack and ControlNet bandwidth-limited systems
Supports up to 100 Modbus commands, allowing multi-device integration and centralized process control
Compatible with RSLogix 5000 via Add-On Instructions (AOI), simplifying programming and system deployment
Built-in Ethernet port supports configuration, diagnostics, and real-time communication monitoring
Web-based interface provides easy access to module status, documentation, and troubleshooting tools

Environment & Certification

Complies with industrial EMC requirements for electromagnetic compatibility in control systems
Supports RoHS-compliant design for environmentally safe and restricted substance control
Built for continuous operation in power generation, process industries, and factory automation systems
Suitable for installation in ControlLogix chassis with robust mechanical and electrical integration
Certified for industrial communication applications requiring reliable Modbus TCP/IP connectivity
Supports long-term deployment in mission-critical automation and monitoring systems

FAQ

Q1: What is the main function of MVI56E-MNETR?
A1: It enables Modbus TCP/IP communication between ControlLogix PACs and Modbus-compatible industrial devices.

Q2: Does the MVI56E-MNETR support both Client and Server modes?
A2: Yes, it supports dual Client/Server architecture for flexible bidirectional communication.

Q3: Why is it called a reduced data block module?
A3: It uses a smaller I/O image size, improving efficiency in remote rack and ControlNet applications.

Q4: Can it be configured remotely?
A4: Yes, it supports Ethernet-based configuration, diagnostics, and web server access for remote management.

Q5: What industries commonly use this module?
A5: It is widely used in power plants, substations, chemical plants, steel mills, and manufacturing automation systems.
