Product Name: Unity Hot Standby Processor with Multimode Ethernet
Brand Name: Schneider Electric
Model Number: 140CPU67060
Place of Origin: France
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales |
Phone/Whatsapp |
|
Jim Pei |
| Product Name | Schneider Electric 140CPU67060 Unity Hot Standby Processor with Multimode Ethernet |
| Manufacturer | Schneider Electric |
| Product Type | Unity Hot Standby Processor with Multimode Ethernet |
| Part Number | 140CPU67060 |
| Place of shipment | Xiamen, China |
| Country of origin | France |
| Clock Frequency | 266 MHz |
| Transmission Mode | Multimode |
| Internal RAM | 512 kB – 512 kB for Data |
| Expandable File Storage | 8 MB with PCMCIA Card |
| Expandable Program Memory | 7168 kB with PCMCIA Card |
| Number of Local Racks | 2 |
| Distributed I/O Stations | 63 stations, 1 rack, 3 Modbus Plus networks |
| Ethernet X80 Remote I/O | Up to 6 Drops / 2 Remote I/O Racks |
| Distributed Discrete I/O Capacity | 8000 Inputs / 8000 Outputs per Modbus Plus Network |
| Distributed Analog I/O Capacity | 500 Inputs / 500 Outputs per Modbus Plus Network |
| Application-Specific I/O | Accurate Time Stamping; Counter; High-Speed Interrupt Inputs; Serial Link |
| Communication Service | Ethernet Router |
| Integrated Hot Standby Interface | 1 × Multimode Optical Fiber |
| Hot Standby Fiber Distance | Up to 4 km between Primary and Secondary PLCs |
| Other Integrated Connections | 1 × USB; 1 × Modbus; 1 × Modbus Plus |
| Modbus Connection | RJ45 |
| Modbus Plus Connection | Female SUB-D 9 |
| Hot Standby Connection | MT-RJ Multimode Fiber Optic |
| Execution Time – Floating Point | 0.4–0.5 µs/instruction |
| Execution Time – Boolean | 0.0525–0.075 µs/instruction |
| Execution Time – Word | 0.045–0.06 µs/instruction |
| Execution Time – Fixed-Point Arithmetic | 0.045–0.06 µs/instruction |
| Processing Performance | 20 Kinst/ms at 100% Boolean; 15 Kinst/ms at 65% Boolean / 35% Numerical |
| System Overhead | 1 ms Master Task; 0.2 ms Fast Task |
| Bus Current Requirement | 2500 mA |
| Local Signalling | Red LED – Ethernet Collision; Green LED – Ethernet Activity (COM) |
| Functions / Checks | Hot Standby; Process Control |
| Certifications | CE; CSA; GOST; UL; Misc. (Marine) |
| Standard | HazLoc |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
The Schneider Electric 140CPU67060 is a high-performance Unity Hot Standby processor designed for the Modicon Quantum automation platform and demanding process-control applications. It features a 266 MHz processor, expandable program and file storage through a PCMCIA card, and integrated Modbus, Modbus Plus, USB, and multimode fiber-optic Hot Standby connectivity. Its dedicated Hot Standby interface supports fiber connections of up to 4 km between primary and secondary PLCs, enabling redundant controller architectures where system availability is critical. With extensive distributed digital and analog I/O capacity, fast instruction execution, and support for Ethernet routing and application-specific control functions, the module is well suited for continuous-process plants, power generation, water treatment, oil and gas facilities, manufacturing systems, and other large-scale automation installations requiring reliable redundant control.
1. What is the Schneider Electric 140CPU67060 used for?
The Schneider Electric 140CPU67060 is used as a redundant PLC processor in Modicon Quantum Hot Standby systems, particularly for industrial processes where continuous controller availability is important.
2. Does the Schneider Electric 140CPU67060 support Hot Standby operation?
Yes. The Schneider Electric 140CPU67060 includes an integrated Hot Standby interface for creating primary and secondary redundant PLC configurations.
3. What is the maximum Hot Standby distance supported by the Schneider Electric 140CPU67060?
The Schneider Electric 140CPU67060 supports a multimode fiber-optic Hot Standby connection of up to 4 km between the primary and secondary controllers.
4. What communication interfaces are integrated into the Schneider Electric 140CPU67060?
The Schneider Electric 140CPU67060 provides USB, Modbus, Modbus Plus, and multimode optical-fiber Hot Standby connections, along with Ethernet routing functionality.
5. Does the Schneider Electric 140CPU67060 support X80 Remote I/O?
Yes. The Schneider Electric 140CPU67060 supports Ethernet X80 Remote I/O configurations with up to six drops and two remote I/O racks as specified.
6. What types of applications are supported by the Schneider Electric 140CPU67060?
The Schneider Electric 140CPU67060 supports process control as well as functions such as accurate time stamping, counters, high-speed interrupt inputs, serial communication, and distributed I/O management.
