Product Name:programmable controller CPU
Brand Name:SCHNEIDER
Model Number:PC-E984-685
Country of Origin:France
Warranty:12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
SCHNEIDER |
Model Number: |
PC-E984-685 |
Country of Origin: |
France |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Parameter | Specification |
|---|---|
| Model | PC-E984-685: Integrated CPU and power supply module for Modicon 984 control systems, designed for high-reliability industrial automation execution. |
| Input Power | Input Power: Supports 115/230 VAC or 125 VDC and 24 VDC isolated sources, enabling flexible industrial power integration. |
| Frequency Range | Frequency: Operates within 47–63 Hz stable range, ensuring compatibility with global power systems. |
| Power Consumption | Input Watts: Approx. 64W nominal consumption for controller operation under standard load conditions. |
| Output Power | Output Watts: Delivers up to 60W regulated output for CPU and system I/O stability. |
| Dimensions | Dimension: 3.10 x 10.5 x 8 inches (79.0 x 266 x 203 mm), compact rack-mounted industrial design. |
| Weight | Weight: Approximately 5 lbs 5 oz (about 2.4 kg), optimized for control cabinet installation. |
| Memory System | Memory: Flash RAM combined with static volatile RAM for reliable program retention and execution. |
| I/O Capacity | I/O Capacity: Supports large-scale local and remote I/O expansion for distributed control architectures. |
The PC-E984-685 is a high-performance programmable controller CPU and power supply module designed for Modicon 984 series automation systems. It integrates stable processing capability with flexible I/O expansion support, making it suitable for medium to large-scale industrial control architectures.
Within the Modicon PC-E984 series (including PC-E984-381, PC-E984-485, and PC-E984-785 variants), the PC-E984-685 stands out for its enhanced system power handling and reliable real-time execution performance, supporting demanding control logic and distributed I/O networks.
Built for industrial-grade environments, the PC-E984-685 delivers stable operation under fluctuating electrical conditions, strong EMI environments, and continuous duty cycles. It is widely used in automation systems requiring high reliability, fast scan response, and long-term operational stability.
Q1: What is PC-E984-685 used for?
A1: It is used as a PLC CPU and power supply module for Modicon 984 industrial automation systems.
Q2: Does PC-E984-685 support both AC and DC input power?
A2: Yes, it supports multiple input sources including AC and DC isolated power configurations.
Q3: Is PC-E984-685 suitable for large I/O systems?
A3: Yes, it is designed for distributed control systems with expandable local and remote I/O capacity.
Q4: What industries commonly use PC-E984-685?
A4: It is widely used in power plants, substations, chemical plants, steel mills, and manufacturing automation.
Q5: Is this module suitable for harsh industrial environments?
A5: Yes, it is engineered for stable operation under EMI, vibration, and continuous industrial workloads.
