Siemens 3RK1903-0AL10 ET200S terminal module Ready For Ship

Siemens 3RK1903-0AL10 ET200S terminal module Ready For Ship

Product Name:ET200S terminal module

Brand Name:SIEMENS

Model Number:3RK1903-0AL10

Country of Origin:Germany

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

siemens 3rk1903 0al10 et200s terminal module ready for ship-1

Overview
Get your discount today
Specifications
Description
Applications
Control & Communication
Environment and Certification
FAQ
Spares
Recommended Products

Overview

Brand Name:	SIEMENS
Model Number:	3RK1903-0AL10
Country of Origin:	Germany
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Get your discount today

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Product Model	3RK1903-0AL10: Siemens ET200S terminal module designed for reverse starter applications with energy bus integration and modular motor control systems
Manufacturer	Siemens: Global automation and electrical engineering company providing industrial control and motor starter solutions
Product Type	Terminal Module TM-RS130-S31-01 S: Interface module for ET200S reverse starter configurations
System Compatibility	ET200S Platform: Modular distributed motor control and automation system
Installation Width	130 mm: Compact modular design suitable for control cabinet integration
Mounting Depth	100 mm: Space-optimized structure for industrial panel installation
Mounting Height	290 mm: Standard vertical configuration for ET200S assemblies
Rated Voltage	500 V AC: Suitable for industrial motor control power circuits
Insulation Voltage	690 V: High insulation strength for safe operation in demanding environments
Operating Current	50 A: Supports medium-power motor starter applications
Frequency	50/60 Hz: Compatible with standard industrial power systems
Conductor Cross Section	Up to 10 mm²: Flexible wiring compatibility for solid and stranded conductors
Protection Class	IP20: Designed for enclosed control cabinet installations
Tightening Torque	2–2.5 N·m: Ensures secure and stable terminal connections

Description

The 3RK1903-0AL10 is a Siemens ET200S terminal module (TM-RS130-S31-01 S) designed for reverse starter configurations in industrial motor control systems. It provides a robust interface for energy bus integration, ensuring stable and efficient power distribution within decentralized automation architectures.

As part of the Siemens SIMATIC ET200S motor starter system, including related modules in the 3RK series, the 3RK1903-0AL10 supports high-reliability switching applications without requiring a separate supply connection. Its compact 130 mm width design allows easy installation in modular control assemblies while maintaining strong electrical insulation performance up to 690 V.

Engineered for demanding industrial environments, this terminal module ensures safe and consistent operation in motor control applications. With high impulse voltage resistance and flexible conductor compatibility, it delivers reliable performance in both standard and heavy-duty automation systems.

Applications

Power plants: Used for generator auxiliary motor control, protection circuits, and stable switching operations in automation systems.
Substations: Enables motorized switchgear control, protection logic, and reliable signal distribution in power networks.
Chemical plants: Supports process motor control, safety interlocking, and automation of pumping and valve systems.
Steel mills: Ensures robust reverse starter operation in high-temperature and high-interference industrial environments.
Machinery manufacturing: Applied in conveyor systems, production lines, and automated motor-driven equipment control.

Control & Communication

Energy bus integration enables stable power distribution across ET200S motor starter modules, ensuring coordinated operation in modular automation systems.
Terminal design supports reverse starter configuration, allowing efficient forward/reverse motor control in industrial drive applications.
Screw-type connection system ensures secure electrical contact and minimizes wiring failure risks in vibration-prone environments.
Compatible with Siemens ET200S control architecture, ensuring seamless integration into distributed automation networks.

Environment and Certification

High dielectric strength up to 690 V insulation rating ensures safe operation in demanding electrical environments.
Designed for industrial cabinet installation with IP20 protection for controlled enclosure applications.
High impulse voltage resistance (6 kV) provides protection against switching surges and electrical spikes.
Suitable for 50/60 Hz industrial networks, ensuring global application compatibility.
Engineered for stable long-term operation in standard industrial temperature and vibration conditions.

FAQ

Q1: What is the main function of 3RK1903-0AL10?
A1: It is a terminal module used in ET200S reverse starter systems for motor control and energy bus integration.

Q2: Does it support motor reversing applications?
A2: Yes, it is specifically designed for reverse starter configurations in industrial automation systems.

Q3: What is the rated voltage of this module?
A3: It supports up to 500 V AC operating voltage with 690 V insulation capability.

Q4: Can it be used outside control cabinets?
A4: No, it has IP20 protection and is intended for enclosed cabinet installation.

Q5: What industries commonly use this terminal module?
A5: It is widely used in power plants, substations, chemical processing, steel mills, and manufacturing systems.
