Product Name: SIMATIC HMI TP1900 Comfort Panel
Brand Name: Siemens
Model Number: 6AV2124-0UC02-0AX1
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Official Siemens product data identifies this device as a TP1900 Comfort touch-operated Comfort Panel with an 18.5-inch widescreen TFT display, 16,777,216 colors, PROFINET and MPI/PROFIBUS DP connectivity, and 24 MB user memory. The information below is organized for clear industrial sourcing and technical review.
| Rated supply voltage | 24 V DC |
| Permissible supply voltage range | 19.2–28.8 V DC |
| Rated current consumption | 1.7 A |
| Starting current inrush I²t | 0.5 A²·s |
| Typical active power input | 41 W |
| Screen diagonal | 18.5 in |
| Display type | TFT widescreen |
| Number of display colors | 16,777,216 |
| Display resolution | 1,366 × 768 pixels |
| Backlight MTBF at 25 °C | 50,000 h |
| Backlight dimming range | 0–100% |
| Direct keys (touch buttons as S7 I/O) | 40 |
| Maximum permissible inclination without external ventilation | 35° |
| Processor type | X86 |
| User data memory | 24 MB |
| Industrial Ethernet interfaces | 2 interfaces (2-port switch + 1 independent port) |
| Combined RS 422/485 interface | 1 |
| USB interfaces | 2 × USB 2.0 |
| SD card slots | 2 |
| Integrated switch ports | 2 |
| Industrial Ethernet status LEDs | 3 |
| Front protection rating | IP65 / Enclosure Type 4 / 4X |
| Rear protection rating | IP20 |
| Operating temperature, vertical landscape installation | 0–45 °C |
| Operating temperature, vertical portrait installation | 0–40 °C |
| Storage and transport temperature | -20–60 °C |
| Maximum operating relative humidity | 90%, non-condensing |
| Pre-installed operating system | Windows Embedded Compact 2013 |
| Online/runtime languages | 32 |
| Project languages | 32 |
| Alarm classes | 32 |
| Bit messages | 6,000 |
| Analog messages | 200 |
| Recipes | 500 |
| Data records per recipe | 1,000 |
| Sales | Phone/Whatsapp | |
|---|---|---|
| Jim Pei | [email protected] | +86 18020776782 |
6AV2124-0UC02-0AX1 is the Siemens SIMATIC HMI TP1900 Comfort Panel, engineered with an 18.5-inch widescreen TFT touch display for clear machine-level visualization. Its 1,366 × 768 resolution, 16.7 million colors, 24 V DC supply, and 24 MB user memory support demanding operator-interface projects. Dual Industrial Ethernet connectivity, PROFINET, MPI/PROFIBUS DP, USB 2.0, and removable memory interfaces help integrate the panel into established automation environments. This Siemens HMI touch panel gives operators a responsive and consistent interface for process monitoring and control. It is a practical choice for industrial automation replacement, maintenance, modernization, and control-panel sourcing. Our team can support availability checks and purchasing requirements for this genuine SIMATIC HMI Comfort Panel.
