Product Name: SIMATIC MP 277 8-inch Key MultiPanel
Brand Name: Siemens
Model Number: 6AV6643-0DB01-1AX1
Place of Origin: Germany
Warranty: 12 Months
Whatsapp: +86 18020776782
Email: [email protected]
| TECHNICAL PARAMETER | OFFICIAL VALUE |
|---|---|
| Model Number | 6AV6643-0DB01-1AX1 |
| Customer-specific configuration | Yes |
| Design of display | TFT |
| Screen diagonal | 7.5 in |
| Size | 7.5" |
| Display type | TFT, 65536 colors |
| Color type | Colors |
| Horizontal image resolution | 640 |
| Vertical image resolution | 480 |
| Resolution (WxH in pixel) | 640 x 480 |
| MTBF backlighting (at 25 °C) | about 50000 hours |
| 02/27/2012 | © Copyright Siemens AG 2012 |
| Control elements | Membrane keyboard |
| Operating options | Keys |
| Function keys, programmable | 26 function keys, 18 with LEDs |
| Keys with LED | Yes |
| freely inscribable membrane keys | Yes |
| Number of function keys with LEDs | 18 |
| Multi-key operation | Yes |
| Number of multi-key operations | 2 |
| Numeric/alphabetical input | Yes / Yes |
| Supply voltage | 24 V DC |
| Processor | ARM |
| Processor type | ARM |
| Type | Flash / RAM |
| Usable memory for user data | 6 MB usable memory for user data |
| Capacity of main memory, maximum | 128 Mbyte |
| Type | Hardware clock, battery backup, synchronizable |
| Interfaces | 1 x RS422, 1 x RS485, 1 x Ethernet (RJ45) |
| Number of RS 485 interfaces | 1 |
| USB port | 2 x USB |
| Multi Media Card slot | 1 x Multi Media Card slot |
| Industrial Ethernet interface | 1 x Ethernet (RJ45) |
| Mounting position | vertical |
| maximum permissible angle of inclination without | +/- 35 ° |
6AV6643-0DB01-1AX1 is an original Siemens SIMATIC MP 277 8-inch Key MultiPanel for industrial automation systems. Official product data identifies its electrical, processing, communication, memory, and environmental characteristics for accurate engineering evaluation. The unit is designed for dependable integration within its designated automation platform. It supports reliable machine or process operation, diagnostics, commissioning, maintenance, and system modernization. The product is suitable for replacement projects and lifecycle support where order-number accuracy is essential. This page provides clear sourcing information for the 6AV6643-0DB01-1AX1 industrial automation product.
6AV6643-0DB01-1AX1 is used in industrial control systems that require dependable operation, communication, monitoring, or processing within the designated Siemens automation platform. Typical environments include manufacturing lines, process plants, material handling systems, utilities, and machine automation.
6AV6643-0DB01-1AX1 is suitable for commissioning, diagnostics, scheduled maintenance, spare-parts replacement, and lifecycle extension projects. It helps engineers maintain compatible installations and restore system availability with the correct order number.
