Product Name: SIMATIC IFP2200 V2 Industrial Flat Panel
Brand Name: Siemens
Model Number: 6AV7863-4MA00-2AA0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp: +86 18020776782
Email: [email protected]
Siemens 6AV7863-4MA00-2AA0 is the SIMATIC IFP2200 V2 built-in industrial flat panel with a 22-inch widescreen multi-touch display. It presents Full HD 1920 × 1080 content in 16:9 format and connects to an external industrial computer through DisplayPort or DVI-D. Two rear USB 2.0 Type A interfaces support peripheral integration, while the supplied 1.8 m DisplayPort/USB cable supports the specified panel-to-PC connection. The standard-design unit operates from 24 V DC and supports landscape or portrait installation.
| Parameter | Official value |
|---|---|
| Product type | SIMATIC IFP2200 V2 industrial flat panel |
| Display | 22 inch, 16:9, 1920 × 1080 |
| Touch | Multi-touch |
| Video interfaces | DisplayPort V1.2; DVI-D |
| USB | 2 × USB 2.0 Type A at rear |
| Included cable | 1.8 m DisplayPort / USB cable |
| Rated supply | 24 V DC |
| Supply range | 19.2 to 28.8 V DC |
| Rated / maximum current | 1 A / 1.3 A |
| Typical / maximum power | 24 W / 30 W |
| Operating temperature | 0 to +45 °C |
| Storage / transport | -20 to +60 °C |
| Humidity | Up to 90%, no condensation |
| Front / rear protection | IP65 / IP20 |
| Front dimensions | 529 × 331 mm |
| Mounting cutout | 513 × 315 mm |
| Mounting depth | 63.4 mm |
| Orientation | Landscape or portrait |
1. What should be checked before replacement?
Confirm full order number, 513 × 315 mm cutout, 63.4 mm depth, 24 V DC supply, video/USB paths, orientation and front sealing.
2. How are video and touch connected?
Use DisplayPort or DVI-D for video and USB for touch; then validate Full HD output, touch alignment and USB enumeration.
3. How is the protection rating preserved?
Mount and seal to Siemens instructions in a suitable enclosure; the front is IP65 and the rear remains IP20.
4. What temperature limits apply?
0 to +45 °C operation, -20 to +60 °C storage/transport, and up to 90% RH without condensation.
5. Can it be mounted in portrait?
Yes. Configure display rotation and touch alignment and verify clearances and cable bend radius.
6. What should procurement request?
Nameplate and connector photos, condition, warranty, included 1.8 m cable, packaging and mounting-accessory scope.
7. How should approvals be checked?
Use the exact nameplate and current Siemens certificates; confirm edition, ambient limits, enclosure, wiring and local authority requirements.
