Product Name: SIMATIC TDC SM500 Signal Module
Brand Name: Siemens
Model Number: 6DD1640-0AH0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Minimum Order Quantity |
1 Piece |
Price |
Contact for Jim |
Packaging Details |
Original new Factory Sealed |
Delivery Time |
3–7 Days |
Payment Terms |
T/T |
Shipping Method |
DHL / FedEx / UPS / TNT |
Supply Ability |
In stock |
| Product Name | Siemens 6DD1640-0AH0 SIMATIC TDC SM500 Signal Module |
| Manufacturer | Siemens |
| Product Type | SIMATIC TDC SM500 Signal Module |
| Part Number | 6DD1640-0AH0 |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Analog Outputs | 8 channels, ±10V, ±10mA, 12-bit, 4 µs conversion |
| Analog Output Protection | Short-circuit to ground |
| Analog Inputs | 8 channels, differential, ±10V, 12-bit, 20 µs, 20 kΩ |
| Integrating Analog Inputs | 4 channels, differential, ±10V, configurable integration time (e.g., 15-bit at 4 ms), 470 kΩ |
| Digital Input Current | Typical 3 mA (Logic "1") |
| Digital Output Current | 50 mA (Rated, Logic "1") |
| Incremental Encoder Inputs | 4 Channels |
| Absolute Encoder Inputs | 4 Channels |
| Status Indicators | 6 LEDs |
| Analog Input Resolution | 12-bit (including sign, with overrange) |
| Analog Output Resolution | 12-bit (including sign, with overrange) |
| Digital Outputs | 16 channels, external 24V supply, 50 mA rated (100 mA max), 100 µs delay |
| Digital Output Protection | Short-circuit to ground (250 mA max), no protection to external supply |
| Digital Inputs | 16 channels, 24V (13.5V high, 6V low), 3 mA typical, 100 µs delay |
|
Sales: |
Email: |
Whatsapp: |
|
Jim Pei |
The Siemens 6DD1640-0AH0 SIMATIC TDC SM500 Signal Module is a high-performance signal processing module designed for SIMATIC TDC automation and drive control systems. It integrates 8 analog inputs, 8 analog outputs, 16 digital inputs, 16 digital outputs, and encoder interfaces for both incremental and absolute encoders, enabling comprehensive signal acquisition and control within a single module. Engineered for high-speed data processing and precise motion control, the SM500 supports seamless integration into SIMATIC TDC platforms, simplifying system architecture while enhancing control performance. It is an ideal solution for demanding industrial applications such as drive control, motion control, process automation, and complex machine systems.
