Product Name:ET 200S distributed I/O Digital electronic module 4DO DC24V/0.5A ST
Brand Name:Siemens
Model Number:6ES7132-4BD02-0AA0
Country of Origin:Germany
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Siemens |
Model Number: |
6ES7132-4BD02-0AA0 |
Country of Origin: |
Germany |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Item | Specification |
|---|---|
| Model | 6ES7132-4BD02-0AA0 |
| Product Type | Digital Output Module |
| System | Siemens ET 200S |
| Output Channels | 4 DO |
| Rated Voltage | 24 V DC |
| Output Current | 0.5 A per channel |
| Total Output Current | Max. 2 A |
| Cable Length | Up to 1000 m (shielded) |
| Switching Frequency | Up to 800 Hz (resistive load) |
| Dimensions (W×H×D) | 15 × ~130 × ~100 mm |
| Weight | Approx. 40 g |
| Protection | Short-circuit protected |
| Isolation | Between backplane and channels |
| Operating Temperature | 0 to 55 °C |
The 6ES7132-4BD02-0AA0 is a SIMATIC ET 200S digital output module designed for reliable 24 V DC signal control in distributed automation systems. With four output channels, it provides precise switching capability for industrial actuators such as solenoid valves, relays, and indicator lamps. As part of Siemens ET 200S modular I/O family, it ensures flexible system expansion and stable integration within PLC-based control architectures.
The 6ES7132-4BD02-0AA0 supports 0.5 A output current per channel and delivers fast switching performance with optimized response times for real-time control applications. Its compact 15 mm module width enables high-density installation in control cabinets.
Built for industrial environments, the 6ES7132-4BD02-0AA0 offers short-circuit protection, isochronous operation support, and reliable backplane bus communication, ensuring safe and continuous operation.
Q1: What is the main function of 6ES7132-4BD02-0AA0?
A1: It provides four-channel 24 V DC digital output control for ET 200S systems.
Q2: What devices can it control?
A2: It can drive solenoid valves, relays, and indicator lamps.
Q3: What is the output current per channel?
A3: Each channel supports up to 0.5 A output current.
Q4: Is it suitable for industrial environments?
A4: Yes, it is designed for reliable operation in harsh automation conditions.
Q5: Does it support fast switching applications?
A5: Yes, it supports high-speed switching up to 800 Hz for resistive loads.
