Product Name: SIMATIC DP ET 200S 2 DO Relay Electronic Module
Brand Name: Siemens
Model Number: 6ES7132-4HB00-0AB0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales: |
Email: |
Whatsapp: |
Jim Pei |
| Product Name | Siemens 6ES7132-4HB00-0AB0 SIMATIC DP ET 200S 2 DO Relay Electronic Module |
| Manufacturer | Siemens |
| Product Type | SIMATIC DP ET 200S 2 DO Relay Electronic Module |
| Part Number | 6ES7132-4HB00-0AB0 |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Output Type | Relay Digital Output (DO) |
| Number of Outputs | 2 Relay Outputs |
| Output Voltage | 24 V DC / 230 V AC |
| Switching Current | Up to 5 A (Resistive Load, ≤50°C); 4 A (≤60°C) |
| Module Width | 15 mm |
| Load Voltage (L+) | 24 V DC |
| Reverse Polarity Protection | Yes |
| Current Consumption | 30 mA max. (Load Voltage L+, No Load); 10 mA max. (Backplane Bus 3.3 V DC) |
| Power Loss | Typical 0.6 W |
| Address Space | 2 Bit (Packed); 1 Byte (Unpacked) |
| Relay Output Features | Minimum Load Current 8 mA; Thermal Continuous Current 5 A |
| Switching Frequency | 2 Hz (Resistive Load); 0.5 Hz (Inductive Load); 2 Hz (Lamp Load) |
| Cable Length | 1000 m (Shielded); 600 m (Unshielded) |
| Status Indication | Green LED for Digital Output; SF (Group Fault) LED (First-Up Signal) |
| Behavior on CPU/Master STOP | Substitute Value / Keep Last Value (Channel-wise, Parameterizable) |
| Isolation Voltage | 1500 V AC (Channels to Backplane Bus/Load Voltage); 500 V DC (Load Voltage to Backplane Bus) |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
The Siemens 6ES7132-4HB00-0AB0 SIMATIC DP ET 200S 2 DO Relay Electronic Module is a 2-channel relay digital output module for the SIMATIC ET 200S distributed I/O system. It supports switching of 24 V DC and 230 V AC loads with relay outputs rated up to 5 A, making it suitable for controlling motors, solenoids, lamps, and other industrial devices. Featuring diagnostic LEDs, configurable output behavior, and high isolation, the module provides reliable performance in industrial automation applications.
Compared with similar relay output modules, the Siemens 6ES7132-4HB00-0AB0 offers higher switching flexibility, reliable isolation, and dependable industrial performance.
Q1: What is the 6ES7132-4HB00-0AB0 used for?
A1: 6ES7132-4HB00-0AB0 is used to control relay-based digital outputs in SIMATIC ET 200S distributed I/O systems.
Q2: How many relay outputs does the 6ES7132-4HB00-0AB0 provide?
A2: 6ES7132-4HB00-0AB0 provides 2 relay output channels.
Q3: What output voltages are supported by the 6ES7132-4HB00-0AB0?
A3: 6ES7132-4HB00-0AB0 supports switching 24 V DC and 230 V AC loads.
Q4: What is the maximum switching current of the 6ES7132-4HB00-0AB0?
A4: 6ES7132-4HB00-0AB0 supports switching currents up to 5 A for resistive loads.
Q5: What is the module width of the 6ES7132-4HB00-0AB0?
A5: 6ES7132-4HB00-0AB0 has a compact 15 mm module width.
Q6: Does the 6ES7132-4HB00-0AB0 provide diagnostic functions?
A6: 6ES7132-4HB00-0AB0 includes LED status indicators and a group fault (SF) LED for diagnostics.
