Product Name: Analog Input Module
Brand Name: Siemens
Model Number: 6ES7134-4GB01-0AB0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales |
||
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
| Product Name | Siemens 6ES7134-4GB01-0AB0 Analog Input Module |
| Manufacturer | Siemens |
| Product Type | Analog Input Module |
| Part Number | 6ES7134-4GB01-0AB0 |
| Weight | 0.05kg |
| Estimated shipping dimensions | 1.4x5.5x8.3cm |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Rated value (DC) | 24 V; From power module |
| Reverse polarity protection | Yes; Destruction limit 35 mA per channel |
| from load voltage L+ (without load), max | 80 mA |
| from backplane bus 3.3 V DC, max. | 10 mA |
| Power loss, typ. | 0.6 W |
| Address space per module, max. | 4 byte |
| Number of analog inputs | 2 |
| Conversion time (per channel) | 65 ms; 55 / 65 ms |
| Integration time (ms) | 16,7 / 20 ms |
| Crosstalk between the inputs, min. | -50 dB |
The Siemens 6ES7134-4GB01-0AB0 is a SIMATIC ET 200S analog input module designed for accurate acquisition and processing of analog signals in distributed automation systems. Featuring two analog input channels, the module enables reliable monitoring of process variables from field devices and sensors, making it suitable for applications such as process control, manufacturing automation, energy management, and industrial monitoring.
The Siemens 6ES7134-4GB01-0AB0 combines high measurement accuracy, low power consumption, and compact installation dimensions to optimize control cabinet space. With integrated reverse polarity protection, low crosstalk performance, and stable signal conversion capabilities, it ensures dependable operation even in demanding industrial environments where precise analog data acquisition is critical.
The primary function of the Siemens 6ES7134-4GB01-0AB0 is to acquire analog signals from field devices and convert them into digital values that can be processed by a PLC or distributed I/O system.
Key functions include:
Compared with conventional analog input modules, the Siemens 6ES7134-4GB01-0AB0 provides improved measurement stability, efficient space utilization, and seamless integration within ET 200S automation systems.
1. Excellent Signal Isolation Performance
With crosstalk levels as low as -50 dB, the Siemens 6ES7134-4GB01-0AB0 delivers more accurate signal acquisition than many standard analog input modules.
2. Compact ET 200S Design
The Siemens 6ES7134-4GB01-0AB0 occupies minimal installation space, making it ideal for high-density control cabinets and distributed I/O architectures.
3. Enhanced Protection Features
Integrated reverse polarity protection helps safeguard the module and connected systems against wiring errors, reducing maintenance risks.
4. Low Power Consumption
With a typical power loss of only 0.6 W, the Siemens 6ES7134-4GB01-0AB0 contributes to improved energy efficiency compared with many competing analog modules.
5. Reliable Measurement Performance
Optimized conversion and integration times provide stable analog signal processing in industrial environments with fluctuating electrical conditions.
6. Seamless Siemens Integration
Native compatibility with the ET 200S platform simplifies engineering, commissioning, and maintenance compared with third-party analog input solutions.
Q1: How many analog input channels does 6ES7134-4GB01-0AB0 provide?
A: The Siemens 6ES7134-4GB01-0AB0 provides two analog input channels for industrial signal acquisition applications.
Q2: Does 6ES7134-4GB01-0AB0 include reverse polarity protection?
A: Yes, the Siemens 6ES7134-4GB01-0AB0 features integrated reverse polarity protection to help prevent damage caused by incorrect wiring.
Q3: What is the conversion time of 6ES7134-4GB01-0AB0?
A: The Siemens 6ES7134-4GB01-0AB0 offers a conversion time of approximately 55–65 ms per channel, ensuring reliable analog signal processing.
Q4: What automation systems are compatible with 6ES7134-4GB01-0AB0?
A: The Siemens 6ES7134-4GB01-0AB0 is specifically designed for use within Siemens SIMATIC ET 200S distributed I/O systems.
Q5: Why is low crosstalk important in 6ES7134-4GB01-0AB0?
A: The low crosstalk performance of the Siemens 6ES7134-4GB01-0AB0 helps maintain signal accuracy by minimizing interference between input channels, resulting in more reliable measurement data.
