Siemens 6ES7153-2BA02-0XB0 ET 200M INTERFACE IM 153-2 HIGH FEATURE FOR MAX In stock

Siemens 6ES7153-2BA02-0XB0 ET 200M INTERFACE IM 153-2 HIGH FEATURE FOR MAX In stock

Product Name:ET 200M INTERFACE IM 153-2 HIGH FEATURE FOR MAX

Brand Name:Siemens

Model Number:6ES7153-2BA02-0XB0

Country of Origin:Germany

Warranty: 12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

siemens 6es7153 2ba02 0xb0 et 200m interface im 153 2 high feature for max in stock-1

Overview
Contact for quotation
Specifications
Description
Applications
Features
Functions
FAQ
Spares
Recommended Products

Overview

Brand Name:	Siemens
Model Number:	6ES7153-2BA02-0XB0
Country of Origin:	Germany
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Item	Specification
Product Model	6ES7153-2BA02-0XB0
Product Type	ET 200M Interface Module (DP HF)
System	Siemens SIMATIC ET 200M
Communication Protocol	PROFIBUS DP (EN 50170)
Transmission Rate	Up to 12 Mbit/s
Supported Modules	Max. 12 S7-300 modules
Address Area	244 bytes input / 244 bytes output
Time Stamping Accuracy	1 ms (up to 8 modules)
Time Format	RFC 1119
Power Supply	24 V DC
Power Consumption	~600 mA
Power Loss	~5.5 W
Backplane Output	5 V DC / 1.5 A
Isolation	500 V tested
Dimensions (W×H×D)	40 × 125 × 117 mm
Weight	~360 g

Description

The 6ES7153-2BA02-0XB0 is a high-feature Siemens SIMATIC DP interface module designed for the ET 200M distributed I/O system. It enables reliable PROFIBUS DP communication and supports up to 12 S7-300 modules per station, making it suitable for advanced industrial automation architectures requiring flexible and scalable I/O expansion.

The 6ES7153-2BA02-0XB0 offers enhanced system capabilities including redundancy support, time stamping functions, and isochronous mode operation. It also supports extended diagnostics and HART data processing, ensuring precise and real-time field communication in complex control environments.

Built for demanding process and factory automation systems, the 6ES7153-2BA02-0XB0 delivers stable data exchange, high-speed communication up to 12 Mbit/s, and robust electrical isolation, making it ideal for continuous operation in industrial networks.

Applications

Applications Power plants: Used for generator set status monitoring and relay protection.
Substations (substations): Enable bus differential control, line protection, and switchyard signal acquisition.
Chemical plants: Integrate process control automation and intrinsically safe signal monitoring.
Steel mills (metallurgical plants): Perform high-speed control logic in harsh EMI and high-temperature environments.
Machinery manufacturing plants: Used for automated production lines, robotics systems, and packaging equipment control.

Features

High-feature ET 200M PROFIBUS DP interface
Supports redundancy architecture
Time stamping with 1 ms accuracy
Isochronous mode operation support
Up to 12 modules per station
HART extended data handling capability
Stable industrial-grade isolation design
High-speed communication up to 12 Mbit/s

Functions

PROFIBUS DP slave communication
Distributed I/O module integration
Real-time signal transmission and synchronization
Time-stamped event processing
Redundant system operation support
Field device data acquisition and management
High-precision automation control support

FAQ

Q1: What system is the 6ES7153-2BA02-0XB0 used for?
A1: It is used in Siemens ET 200M distributed I/O systems.

Q2: How many modules can it support per station?
A2: It supports up to 12 S7-300 modules.

Q3: Does it support redundancy?
A3: Yes, it includes redundancy support for high reliability systems.

Q4: What communication protocol does it use?
A4: It uses PROFIBUS DP up to 12 Mbit/s.

Q5: Is time stamping supported?
A5: Yes, it provides 1 ms time stamping accuracy.
