Product Name:16-channel spring-type terminal module
Brand Name:Siemens
Model Number:6ES7193-1CH10-0XA0
Country of Origin:Germany
Warranty:12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Siemens |
Model Number: |
6ES7193-1CH10-0XA0 |
Country of Origin: |
Germany |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Item | Specification |
|---|---|
| Product Model | 6ES7193-1CH10-0XA0, SIMATIC DP TB16L terminal block for ET 200L, Siemens distributed I/O spare part |
| System Compatibility | ET 200L distributed I/O system, spring-type terminal interface for field wiring |
| Channel Capacity | 16 channels, supports multi-point signal connection for automation systems |
| Wiring Type | Spring-clamp terminal technology, tool-free and vibration-resistant connection method |
| Mounting Type | DIN rail mounting, stable installation in industrial control cabinets |
| Dimensions | Width 145 mm, compact design for modular I/O integration |
| Height | 100 mm, 82 mm with electronics block from DIN rail top edge including bus connector |
| Depth | 40.5 mm, space-efficient installation in control panels |
| Weight | Approx. 230 g, lightweight construction for easy handling and installation |
| Operating Use | Designed for industrial signal distribution in distributed control and automation systems |
The 6ES7193-1CH10-0XA0 is a 16-channel spring-type terminal module designed for reliable signal distribution in distributed I/O systems. It is used within ET 200L distributed I/O system architectures, providing a stable and organized wiring interface for field devices in industrial automation environments.
This terminal block ensures efficient electrical connection between sensors, actuators, and automation controllers. Its spring-clamp design allows tool-free wiring, improving installation speed and reducing maintenance effort while maintaining strong mechanical stability and long-term contact reliability.
As a key spare part in SIMATIC DP systems, the 6ES7193-1CH10-0XA0 supports compact cabinet integration and is optimized for space-saving mounting on DIN rails, making it suitable for modern high-density industrial control systems.
Q1: What is the main use of 6ES7193-1CH10-0XA0?
A1: It is used as a 16-channel terminal block for ET 200L systems to distribute field signals in industrial automation.
Q2: How many channels does it support?
A2: It supports up to 16 spring-type wiring channels for sensor and actuator connections.
Q3: What wiring technology does it use?
A3: It uses spring-clamp technology for tool-free, fast, and vibration-resistant wiring.
Q4: Is it compatible with DIN rail mounting?
A4: Yes, it is designed for standard DIN rail installation in control cabinets.
Q5: What industries commonly use this terminal block?
A5: It is widely used in power plants, chemical processing, steel manufacturing, and automated production systems.
|
