Product Name: SIMATIC S7-300 CPU 315T-3 PN/DP
Brand Name: Siemens
Model Number: 6ES7315-7TJ10-0AB0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp: +86 18020776782
Email: [email protected]
| TECHNICAL PARAMETER | OFFICIAL VALUE |
|---|---|
| Model Number | 6ES7315-7TJ10-0AB0 |
| Hardware product version | 01 |
| Firmware version | CPU: V3.2; integrated technology V4.1.5 |
| 24 V DC | Yes |
| permissible range, lower limit (DC) | 19.2 V |
| permissible range, upper limit (DC) | 28.8 V |
| External protection for supply cables (recommendation) | 2 A min. |
| Rated value (DC) | 24 V |
| Reverse polarity protection | Yes |
| Rated value (DC) | 24 V ; (2L+) |
| Reverse polarity protection | No ; (2L+) |
| Current consumption (rated value) | 1050 mA |
| Current consumption (in no-load operation), typ. | 230 mA |
| Inrush current, typ. | 6.5 A |
| I²t | 1 A²·s |
| Power loss, typ. | 7.5 W |
| integrated | 384 kbyte |
| expandable | No |
| Size of retentive memory for retentive data blocks | 128 kbyte |
| pluggable (MMC) | Yes |
| pluggable (MMC), max. | 8 Mbyte |
| Data management on MMC (after last programming), min. | 10 a |
| present | Yes ; Guaranteed by MMC (maintenance-free) |
| without battery | Yes ; Program and data |
| for bit operations, typ. | 0.05 µs |
| for word operations, typ. | 0.09 µs |
| for fixed point arithmetic, typ. | 0.12 µs |
| for floating point arithmetic, typ. | 0.45 µs |
| Number of blocks (total) | 1024 ; (DBs, FCs, FBs); the maximum number of loadable blocks |
| Number, max. | 1024 ; Number range: 1 to 16000 |
| Size, max. | 64 kbyte |
| Number, max. | 1024 ; Number range: 0 to 7999 |
| Number of free cycle OBs | 1 ; OB 1 |
| Number of time alarm OBs | 1 ; OB 10 |
| Number of delay alarm OBs | 2 ; OB 20, 21 |
6ES7315-7TJ10-0AB0 is an original Siemens SIMATIC S7-300 CPU 315T-3 PN/DP for industrial automation systems. Official product data identifies its electrical, processing, communication, memory, and environmental characteristics for accurate engineering evaluation. The unit is designed for dependable integration within its designated automation platform. It supports reliable machine or process operation, diagnostics, commissioning, maintenance, and system modernization. The product is suitable for replacement projects and lifecycle support where order-number accuracy is essential. This page provides clear sourcing information for the 6ES7315-7TJ10-0AB0 industrial automation product.
6ES7315-7TJ10-0AB0 is used in industrial control systems that require dependable operation, communication, monitoring, or processing within the designated Siemens automation platform. Typical environments include manufacturing lines, process plants, material handling systems, utilities, and machine automation.
6ES7315-7TJ10-0AB0 is suitable for commissioning, diagnostics, scheduled maintenance, spare-parts replacement, and lifecycle extension projects. It helps engineers maintain compatible installations and restore system availability with the correct order number.
