Product Name: SIMATIC S7-300 CPU 317T-2 DP Technology CPU
Brand Name: Siemens
Model Number: 6ES7317-6TK13-0AB0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales: |
Email: |
Whatsapp: |
Jim Pei |
| Product Name | Siemens 6ES7317-6TK13-0AB0 SIMATIC S7-300 CPU 317T-2 DP Technology CPU |
| Manufacturer | Siemens |
| Product Type | SIMATIC S7-300 CPU 317T-2 DP Technology CPU |
| Part Number | 6ES7317-6TK13-0AB0 |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Integrated Work Memory | 1,024 KB |
| Rated Supply Voltage | 24 V DC |
| Supply Voltage Range | 20.4 to 28.8 V DC |
| Load Voltage (L+) | 24 V DC |
| Typical No-Load Current Consumption | 200 mA |
| Typical Inrush Current | 2.5 A |
| Typical Power Dissipation | 6 W |
| Retentive Data Area | All Data Blocks (DBs), Max. 256 KB |
| Digital Inputs | 4 |
| Technology Inputs | 4 High-Speed Inputs |
| Rated Input Voltage | 24 V DC |
| Input Current | Typical 7 mA |
| Input Delay | Max. 10 μs (0→1 / 1→0) |
| Maximum Input Cable Length | 1,000 m (Shielded) |
| Digital Outputs | 8 |
| High-Speed Outputs | 8 |
| Rated Output Voltage | 24 V DC |
| Rated Output Current | 0.5 A per channel |
| Maximum Output Current | 0.6 A per channel |
| Residual Current | Max. 0.3 mA |
| Short-Circuit Threshold | Typical 1 A |
| Inductive Shutdown Voltage Limit | 48 V |
| Lamp Load | Max. 5 W |
| Switching Frequency (Resistive Load) | Max. 100 Hz |
| Switching Frequency (Inductive Load) | Max. 0.2 Hz |
| Total Output Current | 4 A (Horizontal, ≤40 °C); 3 A (≤60 °C) |
| Output Cable Length | 1,000 m (Shielded) |
| Communication Interface 1 | MPI / PROFIBUS DP |
| Transmission Rate | Up to 12 Mbit/s |
| Physical Interface | RS-485 |
| Interface Supply Current | Max. 200 mA |
| Permissible Potential Difference | 75 V DC / 60 V AC |
| Isolation Test Voltage | 500 V DC |
| Operating Temperature | 0 to +60 °C |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
The Siemens 6ES7317-6TK13-0AB0 SIMATIC S7-300 CPU 317T-2 DP Technology CPU is a high-performance technology CPU designed for the SIMATIC S7-300 automation platform. It combines advanced PLC control with integrated motion control functions, featuring 1,024 KB of work memory, high-speed digital inputs and outputs, and an integrated MPI/PROFIBUS DP communication interface with transmission rates up to 12 Mbit/s. The CPU is ideal for demanding applications requiring synchronized positioning, motion control, and high-speed machine automation.
Compared with similar technology CPUs, the Siemens 6ES7317-6TK13-0AB0 offers powerful processing, integrated motion control, and high-speed communication for advanced automation systems.
Q1: What is the 6ES7317-6TK13-0AB0 used for?
A1: 6ES7317-6TK13-0AB0 is used for high-performance PLC control, motion control, and positioning applications in SIMATIC S7-300 automation systems.
Q2: How much work memory does the 6ES7317-6TK13-0AB0 provide?
A2: 6ES7317-6TK13-0AB0 includes 1,024 KB of integrated work memory.
Q3: Which communication interface does the 6ES7317-6TK13-0AB0 support?
A3: 6ES7317-6TK13-0AB0 supports MPI and PROFIBUS DP communication through an RS-485 interface with transmission speeds up to 12 Mbit/s.
Q4: How many digital inputs and outputs does the 6ES7317-6TK13-0AB0 provide?
A4: 6ES7317-6TK13-0AB0 provides 4 digital inputs, 4 high-speed technology inputs, 8 digital outputs, and 8 high-speed outputs.
Q5: What is the supply voltage of the 6ES7317-6TK13-0AB0?
A5: 6ES7317-6TK13-0AB0 operates on 24 V DC with a permissible voltage range of 20.4 to 28.8 V DC.
Q6: What is the maximum digital output current of the 6ES7317-6TK13-0AB0?
A6: 6ES7317-6TK13-0AB0 provides a rated output current of 0.5 A per channel and a maximum of 0.6 A per channel.
