Product Name: SIMATIC S7-300 FM 352 Electronic Cam-Operated Control Module
Brand Name: Siemens
Model Number: 6ES7352-1AH01-0AE0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales |
Phone/Whatsapp |
|
Jim Pei |
| Product Name | Siemens 6ES7352-1AH01-0AE0 SIMATIC S7-300 FM 352 Electronic Cam-Operated Control Module |
| Manufacturer | Siemens |
| Product Type | SIMATIC S7-300 FM 352 Electronic Cam-Operated Control Module |
| Part Number | 6ES7352-1AH01-0AE0 |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Rated Supply Voltage | 24 V DC |
| Current from Load Voltage L+ | 200 mA max. |
| Current from 5 V DC Backplane Bus | 100 mA max. |
| Typical Power Loss | 8.1 W |
| 5 V Encoder Supply Output Current | 300 mA max. |
| 5 V Encoder Cable Length | 32 m max. |
| 24 V Encoder Supply Output Current | 300 mA max. |
| 24 V Encoder Cable Length | 100 m max. |
| Number of Digital Inputs | 4 |
| Digital Input Rated Voltage | 24 V DC |
| Input Voltage for Signal “0” | -3 to +5 V |
| Input Voltage for Signal “1” | +11 to +30 V |
| Input Current for Signal “0” | 2 mA max. |
| Input Current for Signal “1” | 9 mA typ. |
| Number of Digital Outputs | 13 |
| Short-Circuit Protection | Yes |
| Digital Output Rated Voltage | 24 V DC |
| Output Voltage for Signal “1” | UP − 0.8 V min. |
| Output Current for Signal “1” | 5–600 mA at 0–60 °C |
| Residual Current for Signal “0” | 0.5 mA max. |
| Supported Encoders | Symmetrical incremental, asymmetrical incremental, absolute SSI, 2-wire sensor |
| Symmetrical Incremental Encoder Interface | 5 V differential signal (RS-422) |
| Symmetrical Incremental Input Frequency | 1 MHz max. |
| Asymmetrical Incremental Encoder Voltage | 24 V |
| Asymmetrical Incremental Input Frequency | 50 kHz max. (25 m cable); 25 kHz (100 m cable) |
| Absolute Encoder Interface | SSI |
| SSI Signals | DATA/notDATA; CL/notCL |
| SSI Telegram Length | 13 or 25 bit, parameterizable |
| SSI Shielded Cable Length | 320 m max. at 125 kHz |
| Operating Temperature | 0 to 60 °C |
| Storage / Transportation Temperature | -40 to +70 °C |
| Required Front Connector | 1 × 20-pin |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
The Siemens 6ES7352-1AH01-0AE0 is an SIMATIC S7-300 FM 352 electronic cam-operated control module designed for position-dependent switching and high-speed machine control within SIMATIC S7-300 automation systems. It supports incremental and SSI absolute encoders and provides 4 digital inputs and 13 digital outputs for flexible integration with field devices. By processing encoder position signals and controlling outputs according to defined cam positions, the FM 352 enables precise synchronization of mechanical movements and automated sequences, making it suitable for packaging, printing, assembly, material handling, and other motion-oriented machinery.
1. What is the Siemens 6ES7352-1AH01-0AE0 used for?
The Siemens 6ES7352-1AH01-0AE0 is used for electronic cam control and position-dependent switching in automated machinery, enabling machine operations to be synchronized with encoder position signals.
2. How many digital inputs and outputs does the Siemens 6ES7352-1AH01-0AE0 provide?
The Siemens 6ES7352-1AH01-0AE0 provides 4 digital inputs and 13 digital outputs for connecting and controlling compatible field devices.
3. What encoder types does the Siemens 6ES7352-1AH01-0AE0 support?
The Siemens 6ES7352-1AH01-0AE0 supports symmetrical incremental encoders, asymmetrical incremental encoders, SSI absolute encoders, and compatible 2-wire sensors.
4. What is the maximum encoder frequency of the Siemens 6ES7352-1AH01-0AE0?
The Siemens 6ES7352-1AH01-0AE0 supports symmetrical incremental encoder input frequencies up to 1 MHz.
5. Does the Siemens 6ES7352-1AH01-0AE0 support SSI absolute encoders?
Yes. The Siemens 6ES7352-1AH01-0AE0 supports SSI absolute encoders with parameterizable 13-bit or 25-bit telegram lengths.
6. Does the Siemens 6ES7352-1AH01-0AE0 provide short-circuit protection?
Yes. The digital outputs of the Siemens 6ES7352-1AH01-0AE0 include short-circuit protection for reliable field device control.
