Product Name:Control Unit FM 355 C
Brand Name:Siemens
Model Number:6ES7355-0VH10-0AE0
Country of Origin:Germany
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Siemens |
Model Number: |
6ES7355-0VH10-0AE0 |
Country of Origin: |
Germany |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Parameter | Specification |
|---|---|
| Model | 6ES7355-0VH10-0AE0 |
| Product Type | Control Unit FM 355 C |
| System Family | SIMATIC S7-300 |
| Digital Inputs | 8 DI (24 V DC) |
| Analog Inputs | 4 AI |
| Analog Outputs | 4 AO |
| Load Voltage | 24 V DC (20.4–28.8 V DC) |
| Power Loss | Typ. 6.5 W / Max. 7.8 W |
| Input Types | Voltage, Current, TC, RTD |
| Output Types | Voltage 0–10 V, Current 4–20 mA |
| Isolation | Channels to backplane bus (optocoupler) |
| Resolution | Up to 14-bit configurable |
| Cable Length | Up to 1000 m (shielded DI) |
| Front Connector | 2 × 20-pin |
| Dimensions (W × H × D) | 80 × 125 × 120 mm |
| Weight | Approx. 470 g |
The Siemens 6ES7355-0VH10-0AE0 is a multifunction control unit from the SIMATIC S7-300 series, designed for advanced automation tasks requiring combined analog and digital processing. It integrates 4 analog inputs, 8 digital inputs, and 4 analog outputs, providing a compact solution for closed-loop control applications in industrial environments.
Engineered for process control efficiency, the 6ES7355-0VH10-0AE0 supports voltage, current, thermocouple, and resistance temperature measurement, enabling flexible signal acquisition across diverse industrial processes. Its high-resolution conversion and fast response time ensure accurate monitoring and stable control performance.
As part of the SIMATIC S7-300 automation platform, the 6ES7355-0VH10-0AE0 works seamlessly with modules such as 6ES7314-1AF11-0AB0, 6ES7322-1BH01-0AA0, and 6ES7331-7KF02-0AB0, making it suitable for integrated control systems in power generation, manufacturing, and process industries.
Power Plants: Used for turbine auxiliary control, generator monitoring systems, process regulation loops, and relay protection interfaces.
Substations: Enable analog signal acquisition, switchgear automation, transformer monitoring, and protection system integration.
Chemical Plants: Support process instrumentation, temperature control, flow regulation, and safety-critical automation systems.
Steel Mills (Metallurgical Plants): Provide stable control for furnaces, rolling equipment, and high-EMI industrial environments.
Machinery Manufacturing Plants: Used for automated production lines, robotic systems, CNC machines, and precision equipment control.
Water & Wastewater Facilities: Support pump control, filtration systems, chemical dosing, and remote process automation.
Q1: What is the main function of the 6ES7355-0VH10-0AE0?
A1: It is a control unit that integrates analog inputs, digital inputs, and analog outputs for process automation.
Q2: What types of signals can the module measure?
A2: It supports voltage, current, thermocouples, and resistance temperature sensors.
Q3: How many control loops does the module support?
A3: It supports up to 4 closed-loop controllers.
Q4: Is the 6ES7355-0VH10-0AE0 electrically isolated?
A4: Yes, it provides optocoupler isolation between channels and the backplane bus.
Q5: Which industries commonly use this module?
A5: It is widely used in power plants, chemical industries, steel mills, manufacturing, and water treatment systems.
|
