Siemens 6ES7392-1AM00-0AA0 SIMATIC S7-300, Front connector with screw contacts Ready For Ship

Siemens 6ES7392-1AM00-0AA0 SIMATIC S7-300, Front connector with screw contacts Ready For Ship

Product Name:SIMATIC S7-300, Front connector with screw contacts

Brand Name:Siemens

Model Number:6ES7392-1AM00-0AA0

Country of Origin:Germany

Warranty: 12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

siemens 6es7392 1am00 0aa0 simatic s7 300 front connector with screw contacts ready for ship-1

Overview
Contact for quotation
Specifications
Description
Applications
Features
Functions
FAQ
Spares
Recommended Products

Overview

Brand Name:	Siemens
Model Number:	6ES7392-1AM00-0AA0
Country of Origin:	Germany
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Model Number	6ES7392-1AM00-0AA0
Product Type	Front Connector
Series	SIMATIC S7-300
Number of Pins	40-Pole
Connection Method	Screw Terminals
Rated Cable Cross Section	0.14 to 0.75 mm²
AWG Range	24 to 19 AWG
Number of Wires per Terminal	1 or 2 Wires
Stripped Cable Length	6 mm
Tightening Torque	0.4 to 0.7 N·m
Operating Temperature	0°C to 60°C
Storage Temperature	-40°C to 70°C
Compatible System	SIMATIC S7-300
Dimensions (W × H × D)	21.6 × 125 × 40.9 mm
Weight	Approx. 137 g

Description

The 6ES7392-1AM00-0AA0 is a 40-pin front connector designed for Siemens SIMATIC S7-300 automation systems, providing a secure and efficient wiring interface between I/O modules and field devices. Its screw-terminal design ensures stable electrical connections while simplifying installation and maintenance procedures in industrial environments.

Engineered for long-term reliability, the 6ES7392-1AM00-0AA0 supports a wide range of conductor types and cable sizes, making it suitable for diverse automation applications. The compact construction helps optimize cabinet space while maintaining easy access for wiring and servicing operations.

Compatible with various SIMATIC S7-300 digital and analog modules, the 6ES7392-1AM00-0AA0 offers dependable signal transmission, simplified field wiring, and enhanced system organization for manufacturing, process control, and infrastructure automation projects.

Applications

Power Plants: Used for secure wiring of monitoring, protection, and control modules.
Substations: Provides reliable terminal connections for relay and automation systems.
Chemical Plants: Supports field signal wiring in process control applications.
Steel Mills: Ensures stable electrical connections in harsh industrial environments.
Machinery Manufacturing Plants: Connects sensors, actuators, and PLC I/O modules on production lines.
Water Treatment Facilities: Facilitates organized field wiring for process automation systems.
Industrial Automation Systems: Simplifies installation and maintenance of control cabinets and PLC networks.

Features

40-pole connector for SIMATIC S7-300 modules.
Screw-terminal technology for secure wiring.
Supports solid and flexible conductors.
Compact design for efficient cabinet utilization.
Easy installation and maintenance access.
Compatible with various S7-300 I/O modules.
Durable construction for industrial environments.
Wide operating temperature range.

Functions

Provides electrical connection between field devices and PLC modules.
Simplifies signal wiring and cable management.
Ensures reliable transmission of control and monitoring signals.
Supports fast module replacement and maintenance.
Improves organization inside automation cabinets.
Accommodates multiple conductor types and sizes.
Enhances long-term connection stability in industrial systems.

FAQ

Q1: What is the purpose of the 6ES7392-1AM00-0AA0?
A1: The 6ES7392-1AM00-0AA0 is a 40-pole front connector used to connect field wiring to SIMATIC S7-300 I/O modules.

Q2: Which connection technology does the 6ES7392-1AM00-0AA0 use?
A2: It utilizes screw-terminal connections for secure and reliable wiring.

Q3: Is the 6ES7392-1AM00-0AA0 compatible with SIMATIC S7-300 systems?
A3: Yes, it is specifically designed for use with Siemens SIMATIC S7-300 automation modules.

Q4: What conductor sizes can be connected to this front connector?
A4: It supports conductor cross-sections ranging from 0.14 mm² to 0.75 mm² for both solid and flexible wires.

Q5: Why is the 6ES7392-1AM00-0AA0 widely used in industrial automation?
A5: Its robust design, easy wiring, reliable connections, and compatibility with S7-300 systems make it ideal for industrial control applications.
