Product Name: Power Supply Module
Brand Name: Siemens
Model Number: 6ES7505-0RA00-0AB0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Minimum Order Quantity |
1 Piece |
Price |
Contact for Jim |
Packaging Details |
Original new Factory Sealed |
Delivery Time |
3–7 Days |
Payment Terms |
T/T |
Shipping Method |
DHL / FedEx / UPS / TNT |
Supply Ability |
In stock |
|
Sales: |
Email: |
Whatsapp: |
|
Jim Pei |
| Product Name | Siemens 6ES7505-0RA00-0AB0 Power Supply Module |
| Manufacturer | Siemens |
| Product Type | Power Supply Module |
| Part Number | 6ES7505-0RA00-0AB0 |
| Weight | 0.58kg |
| Estimated shipping dimensions | 6.8x12.5x14.7cm |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Rated Input Voltage | 24 V DC / 48 V DC / 60 V DC |
| Input Voltage Range | Static 19.2～72 V DC; Dynamic 18.5～75.5 V DC |
| Power Buffer Time | 20 ms |
| Rated Input Current (24V) | 3 A |
| Rated Input Current (48V) | 1.5 A |
| Rated Input Current (60V) | 1.2 A |
| Backplane Bus Power Supply | 60 W |
| Rated Power Consumption | 12 W |
| Status Indicator | LED Status Indicator |
| Electrical Isolation | Main/Secondary Side Reinforced Isolation |
| Isolation Test Voltage | 2500 V DC / 2 s |
| Protection Rating | IP20 |
The Siemens 6ES7505-0RA00-0AB0 is a power supply module designed for SIMATIC S7-1500 automation systems, providing reliable power to the PLC backplane bus. It supports 24 VDC, 48 VDC, and 60 VDC input voltages with a wide operating input range, offering flexibility for different industrial power systems. The module delivers 60 W of backplane bus power, features 20 ms power buffering, reinforced electrical isolation, and LED status indication for simplified monitoring. It is designed to ensure stable operation of the S7-1500 system in industrial automation applications.
Supplies power to the SIMATIC S7-1500 backplane bus.
Supports 24 VDC, 48 VDC, and 60 VDC industrial power systems.
Provides stable power distribution for PLC modules installed in the rack.
Maintains system operation during short-term power interruptions through integrated power buffering.
Monitors operating status via built-in LED indicators.
Provides reinforced electrical isolation to improve system protection and operational safety.
Compared with conventional PLC power supply modules, the Siemens 6ES7505-0RA00-0AB0 offers wider DC input compatibility, integrated power buffering, and enhanced electrical isolation. Its design helps improve system reliability while simplifying integration into S7-1500 automation platforms.
