Siemens 6ES7515-2FM01-0AB0 is a failsafe SIMATIC S7-1500 CPU 1515F-2 PN for standard and safety-related automation. It provides two PROFINET interfaces, with a two-port IRT switch on X1 and a separate RT interface on X2.
This spare-part CPU requires a SIMATIC Memory Card and must be commissioned with a compatible TIA Portal project, firmware level and PROFIsafe configuration. Preserve the verified safety project and device data before replacement.
| Item | Details |
|---|---|
|
Quotation
|
Contact us for current price and availability
|
|
Payment
|
T/T and other agreed terms
|
|
Lead time
|
Confirmed with the quotation
|
|
Shipping
|
DHL, FedEx, UPS or agreed freight service
|
|
Warranty
|
12 months
|
| Technical parameter | Value |
|---|---|
|
Product type designation
|
CPU 1515F-2 PN
|
|
Article number
|
6ES7515-2FM01-0AB0
|
|
Hardware functional status
|
FS03
|
|
Firmware version
|
V2.9
|
|
Program work memory
|
750 KB
|
|
Data work memory
|
3 MB
|
|
PROFINET interface X1
|
Two-port switch with PROFINET IRT
|
|
PROFINET interface X2
|
One port with PROFINET RT
|
|
Bit performance
|
30 ns
|
|
Engineering
|
TIA Portal V17 for FW V2.9; V13 or higher from FW V1.5
|
|
Safety capability
|
PROFIsafe; up to SIL 3 and PL e
|
|
Supply
|
24 V DC, permissible 19.2 to 28.8 V
|
| CONTACT |
Jim Pei
|
|---|
The CPU 1515F-2 PN combines standard PLC execution and failsafe control in one S7-1500 controller. Its separated PROFINET interfaces support machine networking, real-time device communication and integration into a wider plant architecture.
A failsafe CPU replacement requires controlled handling of the safety program, signatures, passwords, hardware configuration, firmware and SIMATIC Memory Card. Validate the restored project and every safety function under the machine builder's approved procedure.
SupplyPLCs supports industrial automation buyers, maintenance teams and system integrators with model-specific sourcing and documentation assistance. Each quotation is checked against the complete order number, requested condition and destination requirements.
To reduce compatibility risk, send clear nameplate photos, installed hardware and software information, machine documentation and the required delivery date. These details help compare the requested item with available stock or a suitable successor before shipment.
Q1. How should I verify that 6ES7515-2FM01-0AB0 is compatible with my existing failsafe project?
Answer: Compare the complete order number, hardware status, firmware, TIA Portal version, configured modules and PROFIsafe devices. Check the safety signature and machine-builder approval before changing the controller.
Q2. What should I back up before replacing 6ES7515-2FM01-0AB0 in a running S7-1500F system?
Answer: Archive the complete TIA Portal project, upload accessible online data, record passwords and device names, save diagnostic information, and protect the original SIMATIC Memory Card until the replacement has passed validation.
Q3. What should I check when PROFINET devices do not reconnect after installing 6ES7515-2FM01-0AB0?
Answer: Verify the correct X1 and X2 cabling, device names, IP settings, topology, media redundancy and firmware compatibility. Compare online diagnostics with the original project before assigning new names or addresses.
Q4. How should I investigate a startup or safety fault reported by 6ES7515-2FM01-0AB0?
Answer: Read the CPU and safety diagnostic buffers, compare the configured and actual hardware, confirm the safety signature, inspect power and PROFINET status, and follow the approved safety restart procedure instead of bypassing a fault.
Q5. What should I review before migrating from 6ES7515-2FM01-0AB0 to its current successor?
Answer: Use the Siemens migration information to compare firmware, TIA Portal support, memory card, safety certificates, network behavior and physical installation. Recompile and fully validate the standard and safety programs.
Q6. Which procurement details should I provide when sourcing 6ES7515-2FM01-0AB0 as a spare?
Answer: Send the CPU nameplate, hardware and firmware status, TIA Portal version, safety-project requirements, SIMATIC Memory Card status, required condition, destination and downtime deadline.
|
