Siemens 6ES7532-5HF00-0AB0 SIMATIC S7-1500 AQ 8xU/I HS Analog Output Module
Siemens 6ES7532-5HF00-0AB0 SIMATIC S7-1500 AQ 8xU/I HS Analog Output Module
Siemens 6ES7532-5HF00-0AB0 SIMATIC S7-1500 AQ 8xU/I HS Analog Output Module
Siemens 6ES7532-5HF00-0AB0 SIMATIC S7-1500 AQ 8xU/I HS Analog Output Module
Siemens 6ES7532-5HF00-0AB0 SIMATIC S7-1500 AQ 8xU/I HS Analog Output Module
Siemens 6ES7532-5HF00-0AB0 SIMATIC S7-1500 AQ 8xU/I HS Analog Output Module
Siemens 6ES7532-5HF00-0AB0 SIMATIC S7-1500 AQ 8xU/I HS Analog Output Module
Siemens 6ES7532-5HF00-0AB0 SIMATIC S7-1500 AQ 8xU/I HS Analog Output Module
Siemens 6ES7532-5HF00-0AB0 SIMATIC S7-1500 AQ 8xU/I HS Analog Output Module
Siemens 6ES7532-5HF00-0AB0 SIMATIC S7-1500 AQ 8xU/I HS Analog Output Module

Siemens 6ES7532-5HF00-0AB0 SIMATIC S7-1500 AQ 8xU/I HS Analog Output Module

SIEMENS / SIMATIC S7-1500
Product Name: SIMATIC S7-1500 AQ 8xU/I HS Analog Output Module
Brand Name:
Siemens
Model Number:
6ES7532-5HF00-0AB0
Place of Origin:
Germany
Warranty:
12 Months
Appurtenance:
siemens 6es7532 5hf00 0ab0 simatic s7 1500 aq 8xu i hs analog output module-1
Inquiry
  • Overview
  • Specifications
  • Contact info
  • Description
  • Function
  • FAQ
  • Our Company History
  • Why Choose Us
  • Other Products
  • Recommended Products

Commercial Terms

Minimum Order Quantity
1 Piece
Price
Contact for Jim
Packaging Details
Original new Factory Sealed
Delivery Time
3–7 Days
Payment Terms
T/T
Shipping Method
DHL / FedEx / UPS / TNT
Supply Ability
In stock

Specifications

Model Number
6ES7532-5HF00-0AB0
Rated supply voltage
24 V DC
Permissible supply range
19.2–28.8 V DC
Maximum supply current
320 mA at 19.2 V
Backplane power requirement
1.15 W
Typical power loss
7 W
Analog output channels
8
Channel grouping
One group of 8
Resolution including sign
16 bit
Minimum all-channel cycle
125 µs
Per-channel conversion time
50 µs
Voltage output ranges
0–10 V; 1–5 V; ±10 V
Current output ranges
0–20 mA; ±20 mA; 4–20 mA
Maximum voltage-output short-circuit current
45 mA
Maximum current-output no-load voltage
20 V
Minimum voltage-output load
1 kΩ
Maximum capacitive load
100 nF
Maximum current-output load
500 Ω
Maximum inductive load
1 mH
Maximum shielded cable length
200 m
Resistive-load settling time
30 µs; manual conditions apply
Capacitive-load settling time
100 µs; manual conditions apply
Inductive-load settling time
100 µs; manual conditions apply
Output ripple at 0–50 kHz
±0.02% of output range
Linearity error
±0.15% of output range
Temperature error
±0.002%/K; doubled below 0 °C
Output crosstalk
-100 dB maximum
Repeat accuracy at 25 °C
±0.05% of output range
Operating error limit
±0.3%; doubled below 0 °C
Basic error limit at 25 °C
±0.2% of output range
Minimum TCO
100 µs
Minimum TDP
250 µs
Permissible S- to MANA difference
8 V DC
Isolation type-test voltage
707 V DC
Operating temperature from FS03
-30 to +60 °C horizontal; -30 to +40 °C vertical

Contact info

Sales
Jim Pei
Phone/Whatsapp

Description

01

Siemens 6ES7532-5HF00-0AB0 is the SIMATIC S7-1500 AQ 8xU/I HS analog output module. Eight voltage or current outputs are arranged in one channel group. The module provides 16-bit resolution and a minimum all-channel cycle of 125 µs. Oversampling is supported for high-speed output applications. The documented output ranges accommodate suitable analog actuators.

02

Diagnostic functions monitor supply and output conditions. Wire-break detection applies to current outputs, while short-circuit diagnosis applies to voltage outputs. Substitute values define the configured response to an interruption. The delivery includes the infeed and shielding components, while the front connector is ordered separately. Check functional status before using safety-oriented load-group shutdown or extended temperature ratings.

Function

A
High-speed analog output
Oversampling supports the scheduled output of analog values in the compatible automation configuration.
B
Output diagnostics
Current and voltage modes provide their respective fault-detection mechanisms and diagnostic indication.
C
Integration and wiring
The module supports appropriate voltage or current actuators; use the matching front connector and shielding arrangement.

FAQ

Q1Is the front connector included with 6ES7532-5HF00-0AB0?
No. The front connector is ordered separately; confirm screw-terminal or push-in requirements.
Q2Which faults can 6ES7532-5HF00-0AB0 identify on its output circuits?
Wire-break monitoring applies to current mode, and short-circuit diagnosis applies to voltage mode.
Q3Is every revision of 6ES7532-5HF00-0AB0 suitable for safety-oriented shutdown?
The data sheet specifies this capability from FS04. Confirm the offered functional status and system conditions.
Q4Does 6ES7532-5HF00-0AB0 allow calibration while the controller is running?
Yes. Calibration and reparameterization in RUN are listed for this module.
Q5Will the functional status of 6ES7532-5HF00-0AB0 be confirmed before delivery?
We can provide label photos and confirm condition; each item is tested before delivery under the agreed warranty.
Q6What happens after payment for an in-stock 6ES7532-5HF00-0AB0?
The item is dispatched immediately and courier tracking is supplied.
