Product Name: SIMATIC ET 200PA SMART DO 32x24V DC/0.5A Digital Output Module with Conformal Coating
Brand Name: Siemens
Model Number: 6ES7650-8EK80-1AA0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales |
Phone/Whatsapp |
|
Jim Pei |
| Product Name | Siemens 6ES7650-8EK80-1AA0 SIMATIC ET 200PA SMART DO 32x24V DC/0.5A Digital Output Module with Conformal Coating |
| Manufacturer | Siemens |
| Product Type | SIMATIC ET 200PA SMART DO 32x24V DC/0.5A Digital Output Module with Conformal Coating |
| Part Number | 6ES7650-8EK80-1AA0 |
| Weight | 0.28kg |
| Estimated shipping dimensions | 4x11.6x12.5cm |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Output Configuration | 32 Digital Outputs |
| Rated Output Voltage | 24 V DC |
| Rated Output Current | 0.5 A per output |
| Output Groups | 4 groups of 8 outputs |
| Input Current | 4.1 A max. per group |
| Output Load | 0.5 A per output; 5 W tungsten |
| Max. Group Current @ 60°C | 6 A per group |
| Max. Group Current @ 40°C | 4 A per group |
| Max. Total Load – Vertical Mounting | 12 A at 60°C; 16 A at 40°C |
| Max. Total Load – Horizontal Mounting | 16 A at 40°C |
| Operating Temperature – Vertical | 0 to 40°C |
| Operating Temperature – Horizontal | 0 to 60°C |
| Conformal Coating | Yes – the -1AA0 version is the conformal-coated variant |
| Hazardous Location Rating | Class I, Div. 2, Groups A, B, C, D; T4 |
| Hazardous Area Marking | II 3 G Ex nA IIC T4 Gc |
| ATEX Certificate | DEKRA 14 ATEX 0018X |
| Certifications / Markings | FM, UL/cUL, CE, KC |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
The Siemens 6ES7650-8EK80-1AA0 is a SIMATIC ET 200PA SMART digital output module designed to control a large number of 24 V DC field devices in distributed automation systems. It provides 32 digital outputs rated at 0.5 A each, arranged in four groups of eight outputs for organized load distribution. As the conformal-coated variant, the module offers additional protection for electronic components when used in challenging industrial environments. Its high channel density, flexible load capacity, and hazardous-area approvals make it suitable for process plants, manufacturing facilities, utilities, and other automation systems requiring reliable control of multiple actuators and discrete loads.
1. Does the Siemens 6ES7650-8EK80-1AA0 have conformal coating?
Yes. The Siemens 6ES7650-8EK80-1AA0 is the conformal-coated version, providing additional protection for its electronic circuitry in demanding industrial environments.
2. How many digital outputs does the Siemens 6ES7650-8EK80-1AA0 provide?
The Siemens 6ES7650-8EK80-1AA0 provides 32 digital outputs arranged in four groups of eight channels.
3. What is the rated output voltage of the Siemens 6ES7650-8EK80-1AA0?
The Siemens 6ES7650-8EK80-1AA0 provides a rated output voltage of 24 V DC.
4. What is the rated output current of the Siemens 6ES7650-8EK80-1AA0?
The Siemens 6ES7650-8EK80-1AA0 supports a rated output current of 0.5 A per output channel.
5. Can the Siemens 6ES7650-8EK80-1AA0 be used in hazardous locations?
Yes. The Siemens 6ES7650-8EK80-1AA0 carries Class I, Division 2 and ATEX hazardous-area ratings for use under the specified installation conditions.
6. What types of loads can the Siemens 6ES7650-8EK80-1AA0 control?
The Siemens 6ES7650-8EK80-1AA0 can control compatible 24 V DC discrete loads such as relays, indicators, solenoid-operated devices, and contactor interfaces within its specified electrical ratings.
