Minimum Order Quantity |
1 Piece |
Price |
Contact for Jim |
Packaging Details |
Original new Factory Sealed |
Delivery Time |
3–7 Days |
Payment Terms |
T/T |
Shipping Method |
DHL / FedEx / UPS / TNT |
Supply Ability |
In stock |
|
Model Number
|
6GK5208-0GA00-2AC2
|
|
Ethernet ports
|
8 × RJ45
|
|
Port transfer rates
|
10/100/1000 Mbit/s
|
|
Console ports
|
1 × RJ11
|
|
Power connection
|
4-pole terminal block
|
|
Signaling connection
|
2-pole terminal block
|
|
Rated supply voltage
|
24 V DC
|
|
Supply range
|
9.6–31.2 V DC
|
|
Maximum current at rated voltage
|
0.26 A
|
|
Maximum supply current
|
0.36 A
|
|
Rated power loss
|
4.3 W
|
|
Input fuse
|
2.5 A / 125 V
|
|
Signaling contact voltage
|
24 V DC
|
|
Signaling contact current
|
0.1 A maximum
|
|
Operating temperature
|
-40 to +70 °C
|
|
Storage temperature
|
-40 to +85 °C
|
|
Transport temperature
|
-40 to +85 °C
|
|
Humidity at 25 °C
|
95% maximum, non-condensing
|
|
Protection class
|
IP20
|
|
Enclosure materials
|
PC-GF10 polycarbonate / die-cast aluminum
|
|
Maximum Ethernet telegram
|
10240 bytes
|
|
Maximum VLANs
|
257
|
|
Maximum dynamic VLANs
|
257
|
|
VLANs with ring redundancy
|
257
|
|
Ring cascade for <0.3 s reconfiguration
|
50 switches
|
|
PROFINET conformity class
|
B
|
|
PROFINET network load class
|
III
|
|
Storage interface
|
C-PLUG slot
|
|
Switching method
|
Store and Forward
|
|
Time synchronization
|
IEEE 1588v2 PTP; NTP / SNTP
|
|
Network management versions
|
SNMP v1 / v2 / v3
|
|
Cybersecurity certification
|
IEC 62443-4-2:2019
|
|
EMC standards
|
EN 61000-6-2, EN 61000-6-4, EN 50121-4
|
|
MTBF
|
54 years
|
|
Mounting options
|
DIN rail, S7-300/S7-1500 rail, wall
|
|
Sales
Jim Pei
|
Email
|
Phone/Whatsapp
|
Siemens 6GK5208-0GA00-2AC2 is the SCALANCE XC208G managed Layer 2 Industrial Ethernet switch. It provides eight gigabit-capable RJ45 ports. The unit includes a console interface and a C-PLUG slot. Redundant power connections support the industrial installation. PROFINET IO and EtherNet/IP integration are included in its documented network capabilities.
Web-based management and the command-line interface provide configuration access. Port diagnostics and traffic statistics assist maintenance of the local network. VLANs can separate configured traffic groups. Supported redundancy protocols allow the switch to form part of a compatible resilient topology. The security features must be configured as part of the plant network design.
|
