Product Name: SCALANCE XR324-12M Managed IE Switch
Brand Name: Siemens
Model Number: 6GK5324-0GG10-1HR2
Place of Origin: Germany
Warranty: 12 Months
Whatsapp: +86 18020776782
Email: [email protected]
Fast response for industrial automation sourcing
| SalesJim Pei | Email[email protected] | Phone/Whatsapp+86 18020776782 |
| PARAMETER | OFFICIAL VALUE |
|---|---|
| Model Number | 6GK5324-0GG10-1HR2 |
| transfer rate | 10, 100, 1000 Mbit/s |
| at DC / rated value | 24 V |
| supply voltage / 1 / rated value | 24 V |
| power loss [W] / 1 / rated value | 44 W |
| consumed current / 1 / maximum | 1.8 A |
| type of electrical connection / 1 / for power supply | 4-pole terminal block |
| fuse protection type / 1 / at input for supply voltage | F 5 A / 125 V |
| during transport | 40 ... +85 °C |
| protection class IP | IP20 |
| at DC / maximum | 0.1 A |
| during operation | 40 ... +70 °C |
| during storage | 40 ... +85 °C |
| note | Reduced operating temperature through the use of media modules (-40 °C to |
| at 25 °C / without condensation / during operation / | 95 % |
| design | 19-inch rack |
| fastening method | When used in shipbuilding, the device must be secured in the 19" rack at four |
| for EMC interference emission | EN 61000-6-4:2007 (Class A) |
| for safety / from CSA and UL | UL 60950-1, CSA C22.2 No. 60950-1-03 |
| MTBF | 25 a |
| warranty period | 5a |
| to website: Selection guide for cables and connectors | https://support.industry.siemens.com/cs/ww/en/view/109766358 |
| for power supply | 1 |
| supply voltage / 1 / voltage range | 19.2 ... 28.8 |
| to web page: SiePortal | https://sieportal.siemens.com/ |
| to website: Industry Online Support | https://support.industry.siemens.com |
| product type designation | XR324-12M |
| Technical Product Detail Page | https://i.siemens.com/1P6GK5324-0GG10-1HR2 |
| for multimode | 24 |
| for operator console | 1 |
| for signaling contact | 1 |
| for media module | 12 |
| product component / connection for redundant voltage supply | Yes |
| product component / 1 / fusing at power supply input | Yes |
| cascading in the case of a redundant ring / at reconfiguration | 100 |
|
01
6GK5324-0GG10-1HR2 is suitable for rear-cabled industrial racks, plant network backbones, control rooms, and modular fiber or copper networks. |
02
It can also support high-availability Ethernet, PROFINET IO, RSTP, VLAN, IGMP, diagnostics, and managed traffic control. |
|
