Product Name: SCALANCE XR324-12M Managed IE Switch
Brand Name: Siemens
Model Number: 6GK5324-0GG10-3AR2
Place of Origin: Germany
Warranty: 12 Months
Whatsapp: +86 18020776782
Email: [email protected]
Fast response for industrial automation sourcing
| SalesJim Pei | Email[email protected] | Phone/Whatsapp+86 18020776782 |
| PARAMETER | OFFICIAL VALUE |
|---|---|
| Model Number | 6GK5324-0GG10-3AR2 |
| Transfer rate | 10 Mbit/s, 100 Mbit/s, 1000 Mbit/s |
| at DC / Rated value | 24 V |
| Fuse protection type / at input for supply voltage | 3.15 A / 250 V |
| Consumed current / maximum | 0.8 A |
| during transport | 40 ... +85 °C |
| Protection class IP | IP20 |
| Product type designation | SCALANCE XR324-12M |
| at DC / maximum | 0.1 A |
| external | 230 V |
| external / minimum | 85 V |
| external / maximum | 264 V |
| at AC / at 230 V | 50 W |
| during operation | 40 ... +70 °C |
| during storage | 40 ... +85 °C |
| at 25 °C / without condensation / during | 95 % |
| Design | 19" rack |
| for safety / from CSA and UL | UL 508, CSA C22.2 No. 142-M1987 |
| for emitted interference | EN 61000-6-4:2007 (Class A) |
| for power supply | 1 |
| for redundant voltage supply | 0 |
| Type of voltage / of the supply voltage | AC |
| to website: Industry Online Support | https://support.industry.siemens.com |
| for multimode | 24 |
| for single mode (LD) | 24 |
| for operator console | 1 |
| for signaling contact | 1 |
| for media module | 12 |
| Product component / fusing at power supply input | Yes |
| Cascading in the case of a redundant ring / at | 100 |
| MIB support | Yes |
| Port mirroring | Yes |
| multiport mirroring | Yes |
| Port diagnostics | Yes |
| VLAN - port based | Yes |
|
01
6GK5324-0GG10-3AR2 is suitable for industrial rack networks, control rooms, plant backbones, and high-port-density Ethernet installations. |
02
It can also support modular copper or fiber media, PROFINET IO, redundancy, VLAN, RSTP, and IGMP networks. |
|
