Product Name: SCALANCE X414-3E Modular Managed Switch
Brand Name: Siemens
Model Number: 6GK5414-3FC00-2AA2
Place of Origin: Germany
Warranty: 12 Months
Whatsapp: +86 18020776782
Email: [email protected]
Siemens 6GK5414-3FC00-2AA2 is the SCALANCE X414-3E modular managed Industrial Ethernet switch for structured plant-network aggregation. The base unit provides two 10/100/1000 Mbps RJ45 ports and twelve 10/100 Mbps RJ45 ports, plus one Gigabit and two 100 Mbit media-module slots and an extender interface. Integrated redundancy management, RSTP, VLAN functions, network management, and the supplied C-PLUG support serviceable brownfield network architectures. Siemens classifies this exact order number as a spare part in product-cancellation status.
| Parameter | Official value |
|---|---|
| Product type | SCALANCE X414-3E modular IE switch |
| Integrated ports | 2 × RJ45 10/100/1000 Mbps; 12 × RJ45 10/100 Mbps |
| Media-module capacity | 1 × Gigabit slot; 2 × 100 Mbit slots |
| Extender interface | 1 |
| Supply voltage | 24 V DC |
| Maximum current | 2 A |
| Typical power loss | 15 W |
| Operating temperature | -40 to +70 °C |
| Storage / transport | -40 to +80 °C |
| Humidity | Up to 95%, no condensation |
| Protection | IP20 |
| Dimensions (W × H × D) | 344 × 145 × 117 mm |
| Removable storage | C-PLUG supported and included |
| Servicing | Hot-swappable interface modules supported |
1. How should a brownfield replacement be verified?
Match the full order number, media modules, extender use, 24 V DC wiring, signaling contact, mounting space, C-PLUG, firmware and active configuration.
2. What should procurement confirm?
Confirm the label, connectors, condition, warranty, C-PLUG and required media modules. The quotation should state the available spare-part condition.
3. How should replacement be prepared?
Document ports, VLANs, redundancy, IP addressing, management access and firmware, then preserve the configuration and C-PLUG before the maintenance window.
4. What environmental limits apply?
-40 to +70 °C operation, -40 to +80 °C storage/transport, up to 95% RH without condensation, and IP20 cabinet installation.
5. How should cybersecurity be assessed?
Compare installed firmware with Siemens support and ProductCERT information; use supported firmware and site backup, test and rollback procedures.
6. Is XM-400 a direct replacement?
No one-for-one equivalence is asserted. Compare interfaces, redundancy, management, power, dimensions, approvals and configuration conversion.
7. What should be tested after commissioning?
Test every required link, speed, VLAN, redundant path, management channel, signaling contact, alarm log and controlled power-cycle recovery.
