Product Name: SCALANCE X SFP992-1 Optical Transceiver
Brand Name: Siemens
Model Number: 6GK5992-1AL00-8AA0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp: +86 18020776782
Email: [email protected]
| Sales | Phone/Whatsapp | |
| Jim Pei | [email protected] | +86 18020776782 |
| Official article number | 6GK5992-1AL00-8AA0 |
| Manufacturer | Siemens AG |
| Product family | SCALANCE X |
| product type designation | SFP992-1 |
| number of electrical/optical connections / for network | 1 |
| number of optical interfaces / for network components or | 1 |
| number of 1000 Mbit/s LC ports / for multimode / integrated | 1 |
| design of the optical interface / for network components or | LC |
| wavelength / of the optical interface | 850 nm; Multi-mode |
| of the transmitter output / minimum | -9.5 dB |
| of the transmitter output / maximum | -2.5 dB |
| of the receiver input / maximum | -3 dB |
| optical sensitivity relating to 1 mW / of the receiver input / | -17 dB |
| attenuation factor / of the FOC transmission link / minimum | 0 dB |
| range / at the optical interface / depending on the optical fiber | 0.35 ... 0.75 km |
| transmission method / for connection type 1 | 1000BASE-SX |
| during operation | -40 ... +85 °C |
| during storage | -40 ... +85 °C |
| during transport | -40 ... +85 °C |
| note | A maximum operating temperature of +85 °C is permissible for a duration of 16 |
| relative humidity / at 25 °C / without condensation / during | 95 % |
| protection class IP | IP20 |
| design | SFP Module |
| width | 14 mm |
| height | 9 mm |
| depth | 57 mm |
| net weight | 0.02 kg |
| fastening method | latched |
| for FM | FM3611: Class 1, Divison 2, Group A, B, C, D / T4, Class 1, Zone 2, Group IIC, |
| for hazardous zone | EN 60079-0: 2006, EN60079-15: 2005, II 3 G Ex nA II T4, KEMA 07 ATEX |
| for safety / from CSA and UL | UL 60950-1, CSA C22.2 No. 60950-1-03 |
| for emitted interference | EN 61000-6-4:2007 (Class A) |
| for interference immunity | EN 61000-6-2:2005 |
| certificate of suitability | EN 61000-6-2:2005, EN 61000-6-4:2007 |
| CE marking | Yes |
| C-Tick | Yes |
| KC approval | No |
| CCC / for hazardous zone according to GB standard | Yes; GB3836.1, GB3836.8 |
| CCC / for hazardous zone according to GB standard / as | Ex nA IIC T4 Gc |
| French marine classification society (BV) | Yes |
| MTBF | 670 a |
| security information | Siemens provides products and solutions with industrial cybersecurity functions |
| For use in hazardous locations | Marine / Shipping |
| FM | CCC-Ex |
| Marine / Shipping | Environment |
| NK / Nippon Kaiji Ky- | Confirmation |
| last modified: | 6/3/2024 |
6GK5992-1AL00-8AA0 is a Siemens SCALANCE X SFP992-1 Optical Transceiver documented with one 1000 Mbit/s LC optical port, 850 nm multimode transmission, and links up to 750 m. These verified characteristics identify the correct hardware for its designated Siemens automation environment. The product performs its assigned role within compatible industrial control, communication, drive, or power architectures. It supports structured engineering, commissioning, and maintenance workflows. Clear Siemens article identification helps technicians source the correct component for replacement and lifecycle service. For professional automation projects, 6GK5992-1AL00-8AA0 provides a dependable, product-specific solution for compatible installations.
