SIEMENS Power Open Processor 562-001 Original new, China SIEMENS Power Open Processor 562-001 Original new Manufacturers, Suppliers, Factory

Overview

Brand Name:	SIEMENS
Model Number:	562-001
Country of Origin:	GERMANY
Packaging Details:	Original new Factory Sealed
Delivery Time:	Delivery time in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Manufacturer	Siemens Building Technologies, Inc. (also Siemens AG) [7†L8]
Part Number	562-001 (SAP: 6BK5790-0AB08-0AA0) [7†L8][8†L11]
Product Type	APOGEE Power Open Processor / 32-Bit CPU Module (Power Open Processor) [5†L3-L4][7†L9][8†L5][9†L6]
Product Line / Series	APOGEE Building Automation System (MBC/RBC controllers) [2†L6-L7][2†L11-L13][7†L11]
Supported Architecture	Open architecture (Power Open platform) [6†L8][8†L11][8†L17]
Communication Protocol	Primary: P2 Protocol (via ALN port) [0†L43]; Supports Ethernet ALN (EALN) via firmware update [0†L44][9†L22-L23]
Automation Level Network (ALN)	Supported (Protocol 2) [0†L43]
Ethernet Automation Level Network (EALN)	Supported (with firmware change) [0†L44][9†L22-L23]
MMI Port	Microphone MMI port; may require modem for public telephone network connection [0†L28][9†L13-L14]
Communication Busses	Module Bus (M-Bus) and Communications Bus (C-Bus) [10†L26-L27]
Memory Configuration	Available in various capacities depending on model variant (e.g., 3 MB, 4 MB, 8 MB total) [10†L15-L17][10†L39-L40]
Firmware Version	2.x (or 1.x depending on variant) [10†L15-L17]
Operating System	Real-time operating system (firmware-based) [11†L46]
Programming Languages	PPCL (APOGEE Powers Process Control Language), STEP 5 (STL, LAD, CSF), plus optional C / Pascal [2†L15-L17][2†L41-L46][3†L19]
Hardware Clock	Real-time clock (RTC) for time stamping [8†L40]
Control Capabilities	Direct Digital Control (DDC) [2†L39-L40]
Diagnostics	Comprehensive self-diagnostics with status LEDs [8†L48-L49]
Power Supply	24 V DC (supplied via system rack) [4†L13] [7†L10] [8†L11]
Operating Temperature	0°C to 40°C (or –25°C to +60°C depending on revision) [4†L22][6†L8][8†L12][8†L24][12†L20]
Storage Temperature	0°C to 50°C [4†L22-L23][8†L25-L26]
Relative Humidity (Operating)	Up to 80% RH (non-condensing) [4†L23-L24][8†L13-L14]
Altitude Rating (Operating)	Up to 1000 m above sea level [4†L24][8†L29-L30]
Dimensions (W x D x H)	140 mm × 110 mm × 72 mm (approx.) [6†L11]
Weight	0.31 kg (0.69 lbs) [4†L18][8†L11]
Certifications	CE for European Economic Area (EEA) when wired per CE guidelines [1†L7-L12]
Product Class	D (Made-to-order / customer-specified; non-reusable engineering product) [4†L23]
RoHS Status	Not RoHS-compliant (per PDF) [2†L15-L16]
WEEE Take-Back	Not available (per PDF) [2†L11-L12]
Country of Origin	Germany [11†L35]
Lifecycle Status	Discontinued (End of Product Lifecycle; PM500); no direct replacement product offered [4†L25-L26]

Description

The Siemens 562-001 APOGEE Power Open Processor is a high‑performance 32‑bit CPU module designed for the Modular Building Controller (MBC) and Remote Building Controller (RBC) within the APOGEE Building Automation System (BAS). This Siemens 562-001 features an open architecture, facilitating flexible configuration and high‑level language programming. Utilizing the Protocol 2 (P2) Automation Level Network (ALN), the 562-001 ensures robust communication. With a firmware update, the 562-001 can also leverage an Ethernet Automation Level Network (EALN), enhancing its connectivity options for modern building management tasks.

Applications

Building Automation Systems (BAS): Central control and monitoring for HVAC, lighting, access control, and fire safety systems.

Direct Digital Control (DDC): Supervisory control and data acquisition for large commercial or industrial facilities.

Field Panel Controller: Serves as a modular DDC field panel in the APOGEE BAS.

Legacy System Integration: Upgrading or replacing outdated MBC/RBC components within existing APOGEE installations.

Process Control: Supporting complex computational tasks in areas such as chemical, pharmaceutical, and food processing plants.

Features

32‑Bit Processing Power: Delivers high computational speed for complex DDC and process control tasks.

Open Architecture: Supports programming in standard industrial languages (STL, LAD, CSF, FBD) and optional high‑level languages (e.g., C, Pascal), offering maximum application flexibility.

Dual ALN Port Operation: Primary communication via Protocol 2 (P2) ALN, with the ability to switch to EALN via a simple firmware change.

Battery‑Backed Real‑Time Clock: Ensures precise time‑stamping of events and alarms, maintaining accurate time even during power outages.

Hot‑Swap Capable: Allows module removal or insertion while the system is powered (provided proper procedure is followed).

CE Marked: Fully compliant with EU directives and standards for sale in the European Economic Area (EEA).

Functions

Executes Control Logic: Runs the APOGEE Powers Process Control Language (PPCL) to automate HVAC, lighting, and other building subsystems.

Manages System Communication: Serves as the main processor, memory, and communications hub for the MBC or RBC field panel.

Performs Process Control: Enables complex closed‑loop PID control of dampers, valves, fans, and pumps.

Provides Remote Access: Supports remote information access (MEDOM) and multi‑user simultaneous operation for facility managers.

Offers Comprehensive Diagnostics: Performs continuous hardware and software self‑tests, with front‑panel LEDs for immediate status and error indication.

Supports High‑Level Math: Executes complex mathematical functions (including floating‑point arithmetic) needed for detailed process engineering models.

FAQ

Q1: What is the Siemens 562-001 used for?
A1: The Siemens 562-001 is a Power Open Processor (32‑bit CPU module) used as a central controller within the APOGEE Modular Building Controller (MBC) or Remote Building Controller (RBC) for building automation systems, handling tasks like HVAC and lighting.

Q2: How do I configure port operation on the 562-001 from P2 ALN to EALN?
A2: The Siemens 562-001 supports both P2 ALN and EALN modes. Switching from its default P2 ALN operation to EALN (Ethernet Automation Level Network) is accomplished by applying a specific firmware change to the processor.

Q3: Is the Siemens 562-001 still available for purchase?
A3: Siemens has discontinued the 562-001 and offers no direct replacement product. However, it remains available in new old stock or refurbished condition from specialized industrial automation suppliers.

Q4: What programming languages are supported by the 562-001?
A4: The Siemens 562-001 can be programmed using standard automation languages (e.g., Statement List, Ladder Diagram, Control System Flowchart) and, optionally, high‑level languages such as C and Pascal for advanced tasks.

Q5: Can the 562-001 be removed or installed while the MBC/RBC panel is powered?
A5: Yes. The Siemens 562-001 supports hot‑swapping; however, it is highly recommended to power off the MBC/RBC panel before insertion or removal. If power must remain on, ensure the lithium battery is engaged and follow all safety procedures to prevent data loss or equipment damage.
