SIEMENS · SCALANCE X-100
6GK5108-0BA00-2AA3
X108 Unmanaged Industrial Ethernet Switch
|
PRODUCT TYPE
8-PORT SWITCH
Confirm configuration before order
|
|
Order check: Confirm port count, supply wiring, signaling contact and network topology before quotation.
|
OFFICIAL PRODUCT OVERVIEW
X108 Unmanaged Industrial Ethernet Switch
The SCALANCE X108 is an unmanaged industrial Ethernet switch for connecting automation devices in star or line network structures. The unit provides eight RJ45 ports for 10/100 Mbps Industrial Ethernet connections.
|
FUNCTION
Industrial networking
|
|
Product type
|
SCALANCE X108
|
|
Ethernet ports
|
8 × RJ45
|
|
Transmission rate
|
10/100 Mbps
|
|
Management
|
Unmanaged
|
|
Diagnostics
|
Device and port LEDs
|
|
Signaling
|
Signaling contact
|
|
Power connection
|
Redundant power supply connection
|
|
CONSTRUCTION
Front-access ports
|
SYSTEM ROLE
Network distribution
Use the X108 to create small Industrial Ethernet star or line structures. Confirm cable category, segment lengths, supply voltage and the required diagnostic concept for the target cabinet.
|
|
PROTECTION
Industrial installation
Environmental limits and approvals depend on the exact product version and installation. Verify the current Siemens technical data before use in the target environment.
|
|
|
BEFORE INSTALLATION
Selection essentials
|
COMMISSIONING
Verify before energizing
|
|
COMMERCIAL CHECK
Quotation basis
|
ORDER PROCESS
What can be confirmed
|
|
