SIEMENS SIMATIC ET 200S 6ES7193-4CD30-0AA0 TM-P15C23-A0 Terminal Module | Original New

SIEMENS SIMATIC ET 200S 6ES7193-4CD30-0AA0 TM-P15C23-A0 Terminal Module | Original New

SIEMENS · SIMATIC ET 200S

6ES7193-4CD30-0AA0

TM-P15C23-A0 Terminal Module

PRODUCT TYPE

15 MM TERMINAL

Confirm configuration before order

Order check: Match the terminal-module coding, compatible electronic module and AUX1 arrangement before quotation.

Email Inquiry WhatsApp [email protected] | +86 18159889985

Overview
Technical Data
Interfaces
Environment
Installation
Verification
Availability
Recommended Models
FAQ & Quote
Recommended Products

OFFICIAL PRODUCT OVERVIEW

TM-P15C23-A0 Terminal Module

The 6ES7193-4CD30-0AA0 is a SIMATIC DP terminal module TM-P15C23-A0 for the ET 200S distributed I/O system. It provides the mechanical and electrical field-wiring base for a compatible plug-in electronic module.

FUNCTION

Field wiring base

Provides field-terminal access for a compatible ET 200S electronic module.
Maintains the module station wiring when the electronic module is replaced.
Supports the specified AUX1 arrangement for the terminal-module variant.

Technical Data

Product designation	TM-P15C23-A0
System	SIMATIC ET 200S
Module width	15 mm
Terminal technology	Cage Clamp / spring-loaded terminals
Terminal arrangement	2 × 3
AUX1	Accessible and interrupted
Compatibility	Confirm before quotation

Interfaces

CONSTRUCTION

ET 200S base

15 mm terminal-module housing.
Field terminals arranged for the specified wiring variant.
Mechanical coding and plug-in interface for a compatible electronic module.
AUX1 access according to the exact TM-P15C23-A0 version.

SYSTEM ROLE

Modular station wiring

The terminal module remains in the ET 200S station as the wiring base while the compatible electronic module plugs into it. Confirm the station design and the approved module pairing before replacement.

Environment

PROTECTION

Cabinet use

Use only within the installation, environmental and hazardous-area conditions specified for the complete ET 200S station. Exact approvals must be verified for the target application.

Installation	ET 200S station
Mounting width	15 mm
Terminal access	Front field wiring
Environmental limits	Refer to current Siemens documentation

Installation

BEFORE INSTALLATION

Selection essentials

Confirm terminal-module designation TM-P15C23-A0.
Match the compatible ET 200S electronic module.
Verify terminal technology and wiring arrangement.
Check the AUX1 distribution required by the station.

COMMISSIONING

Verify before energizing

De-energize field circuits as required by the installation instructions.
Seat the terminal module correctly on the ET 200S mounting system.
Observe conductor preparation and clamping requirements.
Verify wiring and electronic-module coding before commissioning.

Verification

BEFORE ORDER

Verification checklist

Complete article number 6ES7193-4CD30-0AA0.
Terminal-module designation and width.
Compatible electronic module article number.
AUX1 and potential-group arrangement.
Current station approvals and wiring drawing.

Availability

COMMERCIAL CHECK

Quotation basis

Stock status: Confirm before quotation.
Condition: Subject to verification.
Current photos and nameplate: Available on request.
Testing scope and warranty: Subject to quotation.

ORDER PROCESS

What can be confirmed

Dispatch time: Subject to verification.
Payment methods: Confirm before quotation.
Quotation response time: Subject to verification.
Company and transaction documents: Available on request.

Recommended Models

Recommended models

6ES7193-4CD20-0AA0	6ES7193-4CD30-0AA0
6ES7193-4CA50-0AA0	6ES7193-4CB20-0AA0
6ES7193-4CB30-0AA0	6ES7193-6BP00-0BA0
6ES7134-4MB02-0AB0	6ES7134-6TD00-0CA1
6ES7135-6HD00-0BA1	6ES7155-5BA00-0AB0

FAQ & Quote

FAQ

Request quote

Is this exact article available?
Availability is confirmed before quotation. Send the complete model, quantity and destination.

Can I receive current photos and a test statement?
Available on request and subject to the quoted unit and agreed test scope.

What should be supplied for a compatibility check?
Provide the complete article number, hardware configuration, project version and installation details.
