SIEMENS SIMATIC HMI KP1200 Comfort 6AV2124-1MC01-0AX0 Key-Operated Comfort Panel

SIEMENS SIMATIC HMI KP1200 Comfort 6AV2124-1MC01-0AX0 Key-Operated Comfort Panel

6AV2124-1MC01-0AX0

SIMATIC HMI KP1200 Comfort key-operated panel

12.1 inch1280 x 80034 function keysPROFINET

Selection note: Product phase-out has started; confirm successor suitability, software version and installation dimensions before quotation.

Overview
Data
Interfaces
Protection
Installation
Checklist
Commercial
FAQ
Models
Recommended Products

Product Overview

The Siemens SIMATIC HMI KP1200 Comfort 6AV2124-1MC01-0AX0 is a key-operated Comfort Panel with a 12.1-inch widescreen TFT display. It combines a 1280 x 800 display, 34 LED function keys and industrial PROFINET plus MPI/PROFIBUS DP communication.

Applications

Operator control and monitoring for industrial machines
HMI visualization for SIMATIC automation systems
Key-operated applications where tactile function keys are required
PROFINET or PROFIBUS-connected machine panels after project compatibility verification

Technical basis: official Siemens Industry Mall product and technical data for 6AV2124-1MC01-0AX0.

Data

Data

Brand Siemens	Family SIMATIC HMI Comfort Panel	Product type KP1200 Comfort, key operation
Display 12.1-inch widescreen TFT	Resolution 1280 x 800	Colors 16,777,216
Function keys 34, all with LEDs	Configuration memory 12 MB

Interfaces

Interfaces

Industrial Ethernet	PROFINET interface
Fieldbus	MPI/PROFIBUS DP interface
Operator input	34 function keys plus system, numeric and alphanumeric keys
Configuration	WinCC Comfort V11 or later applicable version
Operating system	Windows CE 6.0
Supply	24 V DC, permitted 19.2-28.8 V

Protection

Protection

Backlight service life 80,000 h MTBF at 25 C	Backlight control Dimmable from 0 to 100%	Installation orientation Landscape only
Permitted inclination Up to 35 degrees without external ventilation	Rated input current 0.85 A	Lifecycle Product phase-out started 2026-01-31

Installation

Installation

1	Verify the existing panel cutout and mounting dimensions against the official drawing.
2	Provide a 24 V DC supply within the permitted 19.2-28.8 V range.
3	Install in landscape orientation and respect the permitted inclination.
4	Verify PROFINET or MPI/PROFIBUS DP network settings.
5	Confirm WinCC project compatibility and create a backup before replacement.

Checklist

Checklist

Confirm complete MLFB 6AV2124-1MC01-0AX0.
Confirm key-operated KP1200 Comfort is required rather than a touch panel.
Confirm display, cutout, mounting depth and cable clearances.
Confirm WinCC version and communication interfaces.
Evaluate successor 6AV2128-3MB06-0AX1 only after dimensional verification.

Commercial

Commercial

Stock status	Confirm before quotation
Condition	New, used or refurbished status is subject to verification
Current photographs	Available on request
Warranty	Available on request
Dispatch time	Confirm before quotation
Test status	Scope and records are subject to verification
Payment methods	Available on request
Quotation response	Available on request
Transaction process	Request a formal quotation, traceability details and agreed trade terms

FAQ

FAQ

Q: Is this a touch panel?
A: No. KP1200 Comfort is the key-operated variant.

Q: What is the display resolution?
A: The official technical data specifies 1280 x 800.

Q: Which interfaces are available?
A: The official data lists PROFINET and MPI/PROFIBUS DP.

Q: Is the product still active?
A: The official lifecycle information states product phase-out started on 2026-01-31.

Q: Can the successor be installed directly?
A: Do not assume direct replacement. Siemens notes that successor dimensions should be checked.
