SIEMENS | SIMATIC S7-1200
6ES7241-1CH30-1XB0
CB 1241 RS485 Communication Board
|
RS485
COMMUNICATION
|
OFFICIAL PRODUCT OVERVIEW
A compact serial communications board for SIMATIC S7-1200 installations.
CB 1241 RS485 Communication Board for SIMATIC S7-1200. Technical selection must follow the official Siemens data for the complete article number.
|
RS485
Model: 6ES7241-1CH30-1XB0
Condition and stock status: Subject to verification.
|
|
Interface
|
RS485
|
|
Protocols
|
Freeport, Modbus RTU, USS
|
|
Cable length
|
Up to 1000 m
|
|
Telegram length
|
Up to 1 kbyte
|
|
Power loss
|
1.5 W
|
|
Dimensions
|
38 x 62 x 21 mm
|
|
Weight
|
Approx. 40 g
|
|
Protection
|
IP20
|
|
Physical interface
|
RS485
|
|
Supported operation
|
Freeport and ASCII library
|
|
Industrial protocols
|
Modbus RTU and USS
|
|
Diagnostics
|
Supported
|
|
Backplane current
|
5 V DC, typ. 50 mA
|
|
Connector / wiring
|
Confirm before quotation
|
|
Horizontal installation
|
-20 to +60 C
|
|
Vertical installation
|
-20 to +50 C
|
|
Storage
|
-40 to +70 C
|
|
Relative humidity
|
Up to 95% at 25 C, non-condensing
|
|
Protection
|
IP20
|
|
Cable limit
|
Up to 1000 m
|
|
01
|
Confirm the exact article number and CPU compatibility.
|
|
02
|
Plan RS485 topology, termination and shielding from the official Siemens documentation.
|
|
03
|
Verify protocol mode, baud rate and telegram format before commissioning.
|
|
04
|
Confirm connector and accessory scope before quotation.
|
|
Article number
|
6ES7241-1CH30-1XB0
|
|
System
|
Confirm CPU, rack and engineering configuration
|
|
Accessories
|
Confirm connectors and separately ordered parts
|
|
Electrical data
|
Match field voltage, current and channel arrangement
|
|
Documentation
|
Request current datasheet or official manual when required
|
|
Visual evidence
|
Current unit and nameplate photos available on request
|
|
Stock status
|
Confirm before quotation
|
|
Condition
|
Subject to verification
|
|
Current photos
|
Available on request
|
|
Warranty
|
Confirm before quotation
|
|
Dispatch time
|
Subject to verification
|
|
Testing
|
Available on request and according to agreed scope
|
|
Payment methods
|
Confirm before quotation
|
|
Quote response
|
Subject to verification
|
|
Company and trade documents
|
Available on request
|
|
