Product Name:Galvanic Separation Units
Brand Name:Vibro-Meter
Model Number:GSI130 244-130-000-204
Country of Origin:Switzerland
Warranty:12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Vibro-Meter |
Model Number: |
GSI130 244-130-000-204 |
Country of Origin: |
Switzerland |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Item | Specification |
|---|---|
| Model | GSI130 244-130-000-204 |
| Type | Galvanic separation unit |
| Supply Voltage | 24 V DC ±5% |
| Power Consumption | ~20 mA (no load), up to 60 mA (load) |
| Output Signal | 1 V/mA proportional voltage |
| Frequency Range | DC to 10 kHz |
| Isolation Voltage | ≥4 kVRMS |
| Linearity | ±0.5% |
| Temperature Range | 0°C to +55°C |
| Dimensions | 130 × 74.5 × 23 mm |
| Weight | ~430 g |
The GSI130 244-130-000-204 is a galvanic separation unit from the Vibro-Meter® vibration monitoring range, designed to ensure stable signal transmission and reliable power supply for low-current transducers and signal conditioners. It eliminates ground loop interference and stabilizes measurement chains in industrial monitoring systems.
Operating on a 2-wire transmission principle, the GSI130 provides proportional voltage output based on current consumption, enabling accurate signal evaluation over long distances. It is commonly integrated into vibration protection and condition monitoring systems where signal integrity is critical.
The unit is engineered for industrial environments, offering high electrical isolation up to 4 kVRMS and compliance with international safety standards. By replacing traditional Zener barriers, the GSI130 simplifies installation, reduces voltage drops, and improves overall system performance in demanding automation and machinery protection applications.
Q1: What is GSI130 244-130-000-204 used for?
A1: It is used for galvanic isolation and signal conversion in vibration monitoring and industrial measurement systems.
Q2: Does GSI130 support long-distance signal transmission?
A2: Yes, it is designed for stable signal transmission over long distances with minimal interference.
Q3: What is the isolation level of GSI130?
A3: The unit provides galvanic isolation of up to 4 kVRMS between input and output circuits.
Q4: Can GSI130 replace Zener barriers?
A4: Yes, it eliminates the need for Zener barriers by providing safe signal isolation and power supply control.
Q5: What industries commonly use GSI130?
A5: It is widely used in power plants, steel mills, chemical plants, and industrial automation systems.
|
