Product Name: Relay Output Module
Brand Name: Westinghouse
Model Number: 1C31223G01
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Westinghouse |
Model Number: |
1C31223G01 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
Delivery time in stock |
Payment Terms: |
T/T |
Supply Ability: |
in stock |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Description |
Value |
|
Model |
1C31223G01 |
|
Number of relays |
16 |
|
Relay Type |
G2R electromechanical style with 1 Form C contact style |
|
Relay contact ratings |
10 A @ 250 VAC (PF=1) |
|
Maximum propagation time |
Operate time: 15 ms (bounce ≈ 3 ms) |
|
Dielectric isolation (relay contacts to logic) |
2300 V AC/DC |
|
Relay base power |
Auxiliary power: 9.1 W typical, 11.68 W maximum |
|
Auxiliary power supply |
25 V typical (before output diode drop within Ovation supply) |
|
Operating temperature range |
0 to 60°C (32°F to 140°F) |
|
Storage temperature range |
-40 to 70°C (-40°F to 158°F) |
|
Humidity (non-condensing) |
35% – 85% |
|
Dimensions |
42.2x12.4x8.2cm |
|
Weight |
1.12kg |
The Westinghouse 1C31223G01 is a G2R-style relay output module for Emerson Ovation systems, featuring 16 Form C relays for reliable high AC/DC voltage and current switching in industrial applications.
Power Plant Control: Used in the Ovation DCS to manage critical operations in nuclear, fossil fuel, and hydroelectric power plants.
Industrial Automation: Employed in large-scale manufacturing and processing plants to monitor and control complex machinery.
Water & Wastewater Management: Part of the control infrastructure for monitoring treatment processes and distribution networks.
Utility Infrastructure: Often found in sub-stations or distribution centers to provide circuit protection, switching, and motor controls.
Input/Output (I/O) Processing: Translating signals from field sensors (temperature, pressure, etc.) into data the system can use.
Communication Interface: Allowing different parts of a large control network to "talk" to one another.
Signal Conditioning: Cleaning up electrical signals to ensure accuracy in automated environments.
16 Relay Outputs: Equipped with 16 G2R-style relays for multi-channel switching capability
Form C Contacts: Each relay provides a changeover contact for flexible wiring
High Load Capacity: Supports switching of high AC and DC voltages at elevated currents
Reliable Integration: Designed for seamless use in Emerson Ovation industrial control systems
Signal Switching: Converts control signals into relay-based outputs for field device operation
Load Control: Enables switching of high AC/DC voltage and current loads
Output Interface: Provides terminal block connections for easy integration with external equipment
Control System Expansion: Extends output capabilities within Emerson Ovation systems
Isolation & Protection: Uses electromechanical relays to isolate control circuits from high-power loads
Q1: What is the main function of the Westinghouse 1C31223G01 Relay Output Module (G2R style)?
A1: It provides 16 Form C relay outputs to switch high AC/DC voltages and currents for field devices in Ovation control systems.
Q2: How many relays are included in the 1C31223G01 base assembly?
A2: The module is equipped with 16 G2R-style electromechanical relays, each with a single Form C contact.
Q3: What type of contact configuration does each relay use?
A3: Each relay uses a Form C contact arrangement, allowing one set of changeover contacts to be wired to terminal blocks.
Q4: What applications is the 1C31223G01 typically used for?
A4: It is commonly used in industrial automation and Emerson Ovation DCS systems for switching high-power loads, alarms, and control signals.
Q5: How does the G2R-style relay base differ from KUEP-style bases?
A5: G2R-style bases provide 16 relays, while KUEP-style bases typically offer fewer relays but can handle higher DC voltage switching at higher currents.
