Product Name: Gate Drive PCB Board
Brand Name: Allen Bradley
Model Number:1336-BDB-SP6A
Country of Origin:USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Allen Bradley |
Model Number: |
1336-BDB-SP6A |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
Delivery time in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Parameter |
Details |
|
Product Name |
1336-BDB-SP6A |
|
Product Type |
Gate Drive PCB (Spare Part) |
|
Series Compatibility |
Allen-Bradley 1336 Series (1336 Plus / Plus II / Force / Impact) |
|
Drive Type |
1336STE / 1336F |
|
Rated Voltage |
460V AC |
|
Typical Power Rating |
~30 HP drives |
|
Function |
IGBT / SCR gate signal control |
|
Mounting |
Internal installation in drive |
|
Lifecycle Status |
Obsolete (replaced by newer versions) |
|
Replacement |
1336-CONV-SP6A / SP6D variants |
|
Dimensions |
41x25x4.3cm |
|
Weight |
1.5kg |
1336-BDB-SP6A is a gate driver PCB designed for use in the Allen-Bradley 1336 series AC drives manufactured by Rockwell Automation. The 1336-BDB-SP6A is engineered to control switching signals for power devices, ensuring reliable motor operation. As a legacy spare part, 1336-BDB-SP6A is commonly applied in maintenance and retrofit projects for 1336 Plus and related drives.
Industrial AC motor speed control systems
Pumps, fans, and HVAC drive systems
Conveyor and material handling equipment
Manufacturing automation lines
Legacy 1336 drive repair and refurbishment
Dedicated gate drive control for power semiconductors
Optimized for 1336 series architecture
Stable switching performance under industrial loads
High compatibility with multiple 1336 sub-series
Ideal for spare part replacement and maintenance
Generates gate pulses for IGBT/SCR devices
Controls switching timing in inverter section
Supports efficient motor drive operation
Enhances drive stability and reliability
Interfaces between control board and power stage
Q1: What does 1336-BDB-SP6A do?
A1: The 1336-BDB-SP6A provides gate drive signals to control power switching devices in 1336 AC drives.
Q2: Which drives are compatible with 1336-BDB-SP6A?
A2: It is used in Allen-Bradley 1336 Plus, Plus II, Force, and Impact drives.
Q3: What is the voltage and power rating?
A3: The 1336-BDB-SP6A is typically used in 460V drives around 30 HP.
Q4: Is 1336-BDB-SP6A still available?
A4: It is obsolete but can be sourced as surplus, refurbished, or replacement equivalents.
Q5: What replaces 1336-BDB-SP6A?
A5: It has been replaced by newer versions such as 1336-CONV-SP6A or SP6D variants.
