Product Name:MicroMod MODCELL Multiloop Processor
Brand Name:ABB
Model Number:2002NZ10801C
Country of Origin:SWEDEN
Warranty:12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
ABB |
Model Number: |
2002NZ10801C |
Country of Origin: |
SWEDEN |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Parameter | Specification |
|---|---|
| Product Model | 2002NZ10801C |
| Product Type | MODCELL™ SOE Base Instrument |
| Power Supply | 85–250 VAC |
| Frequency Range | 50–400 Hz |
| Processor | Motorola 68302 Microprocessor |
| Event Recording Accuracy | 1 ms |
| Event Queue Capacity | Up to 1024 Events |
| Communication Network | ICN (Instrument Communication Network) |
| ICN Baud Rate | 31.25 K Baud |
| Modbus Baud Rate | 9600 to 38.4 K Baud |
| Operating Temperature | 0°C to +50°C |
| Storage Temperature | -40°C to +75°C |
| Humidity | 5% to 95% RH, Non-Condensing |
| Power Consumption | 40 W Maximum |
| Peak Inrush Current | 60 A |
| Data Retention | Up to 10 Years (Non-Volatile Memory) |
| Mounting Type | 19-inch Rack Mount |
| Dimensions (H × W × D) | 221.49 × 482.60 × 153.16 mm |
| Weight | 1.42 kg (3 lb 2 oz) |
2002NZ10801C is a high-performance base instrument designed for the MODCELL™ Sequence of Events (SOE) Recorder platform. Engineered for industrial event monitoring applications, it provides a reliable hardware foundation for capturing and recording critical process events with millisecond-level accuracy. The unit is particularly suitable for facilities that require precise event sequencing, fault analysis, and operational diagnostics.
As part of the MODCELL™ architecture, 2002NZ10801C works together with modules such as 2005PZ10102C, 2030NZ10000B, 2032NZ10000C, and optional memory module 2010PZ10000A. Powered by a Motorola 68302 processor, the platform supports high-speed event processing, digital input monitoring, communication management, and time synchronization across multiple controllers.
Designed for power generation, utility, and industrial automation environments, 2002NZ10801C combines robust hardware, flexible communication options, and dependable long-term operation. Its rack-mounted design and support for distributed event recording make it an ideal solution for critical monitoring and sequence-of-events applications.
Power Plants: Used for generator trip monitoring, sequence-of-events recording, alarm tracking, and protection system analysis to improve plant reliability and fault diagnostics.
Substations: Enable event logging, relay operation monitoring, breaker status tracking, and disturbance analysis for electrical transmission and distribution systems.
Chemical Plants: Integrate with process automation systems to record critical events, monitor safety interlocks, and support troubleshooting of process operations.
Steel Mills (Metallurgical Plants): Perform event sequence monitoring and equipment status recording in harsh industrial environments with high temperatures and strong electromagnetic interference.
Machinery Manufacturing Plants: Used for automated production lines, robotic workstations, machine fault tracking, and operational event analysis to enhance productivity and maintenance efficiency.
Q1: What is the primary purpose of the 2002NZ10801C module?
A1: It serves as the base hardware platform for MODCELL™ Sequence of Events recording applications.
Q2: How accurate is event recording on the 2002NZ10801C?
A2: The system provides timestamp accuracy of up to 1 millisecond.
Q3: How many event records can the system store?
A3: The local event queue can store up to 1024 event entries.
Q4: Can multiple 2002NZ10801C units be synchronized?
A4: Yes, multiple units can synchronize time through an RS-485 communication network.
Q5: Which industries commonly use the 2002NZ10801C?
A5: It is widely used in power generation, substations, chemical processing, metallurgy, and industrial automation facilities.
|
