Product Name:Position Monitor
Brand Name:Bently Nevada
Model Number:3500/45 176449-04
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
3500/45 176449-04 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Item | Details |
|---|---|
| Model | 176449-04 |
| Product | 3500/45 Position Monitor |
| Channels | 4 Channels |
| Input Types | Proximitor, RPT, DC LVDT, AC LVDT |
| Power Consumption | 7.7 W typical |
| Dimensions | 241.3 x 24.4 x 241.8 mm |
| Weight | 0.91 kg |
| Mounting | 3500 rack full-height slot |
| Operating Temp | -30°C to +65°C |
| Storage Temp | -40°C to +85°C |
The Bently Nevada 3500/45 Position Monitor (176449-04) is a 4-channel machinery protection module designed for precise position and displacement monitoring in critical industrial assets. It supports a wide range of inputs including proximity probes, DC/AC LVDTs, Rotary Position Transducers (RPTs), and rotary potentiometers, making it highly flexible for different machine configurations. Models such as 3500/45-01, 3500/45-02, and 3500/45-05 are part of the same monitoring family used in rotating equipment protection systems.
The system processes incoming signals and compares them with configurable alarm thresholds to ensure reliable condition monitoring and early fault detection. It is widely applied in turbine control, compressor monitoring, and valve position feedback systems.
With seamless integration into the Bently Nevada 3500 rack system, the 3500/45 (176449-04) delivers stable performance, high accuracy, and industrial-grade reliability for predictive maintenance applications.
Q1: What is the main function of the 3500/45 (176449-04)?
A1: It monitors machine position and provides protection through alarm-based signal comparison.
Q2: Which sensors are compatible with this module?
A2: It supports Proximitor probes, RPTs, DC LVDTs, AC LVDTs, and potentiometers.
Q3: How many channels does it support?
A3: The module supports 4 independent input channels.
Q4: Can it be used in turbine systems?
A4: Yes, it is widely used in turbine vibration and position monitoring applications.
Q5: Is it part of the 3500 rack system?
A5: Yes, it is fully integrated with the Bently Nevada 3500 monitoring platform.
| Number | Describe |
|---|---|
| 176449-04 | 3500/45 Position Monitor |
| 135137-01 | Position I/O Module with internal terminations for Proximitor, RPT or DC LVDT inputs |
| 135145-01 | Position I/O Module with external terminations for Proximitor, RPT or DC LVDT inputs |
| 139554-01 | AC LVDT Position I/O Module with internal terminations for AC LVDT inputs |
| 139567-01 | AC LVDT Position I/O Module with external terminations for AC LVDT inputs |
| 125808-06 | Position-Prox/DC LVDT Euro module |
| 141208-01 | Position-Prox/AC LVDT Euro module |
| 128702-01 | Recorder ET Block Euro |
| 128015-06 | Position external termination block (terminal strip connectors) for Proximitor, RPT and DC LVDT inputs |
| 128710-01 | Recorder external termination block (terminal strip connectors) |
| 166M4363 | Connector header push-in spring type (alternative for PN 00580441) |
| 166M2389 | Connector header push-in spring type (alternative for PN 00580434) |
| 166M2388 | Connector header push-in spring type (alternative for PN 00580432) |
| 166M2379 | Connector header push-in spring type (alternative for PN 00580443) |
