Product Name: Extensible stand-alone central unit
Brand Name: ABB
Model Number:07CT41 1SBP260022R1001
Country of Origin:SWEDEN
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
ABB |
Model Number: |
07CT41 1SBP260022R1001 |
Country of Origin: |
SWEDEN |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
Delivery time in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Parameter |
Specification / Value |
|
Product ID |
1SBP260022R1001 |
|
ABB Type Designation |
07CT41 |
|
Series |
Advant Controller 31 (AC31) |
|
Power Supply |
24 V DC {pdf:1 ; 10†L17} |
|
Inputs |
8 x Digital Inputs (24V DC, isolated) {pdf:1 ; 5†L5} |
|
Outputs |
6 x Transistor Outputs (24V DC / 0.5A) {pdf:1 ; 5†L5} |
|
Processing Speed |
1.2 ms for 1000 instructions (65% Logic, 35% Word) {pdf:2} |
|
Memory |
34 kB total (4.4 kB User Data / Program Flash EPROM) {5†L7} |
|
Communication |
RS232 (Programming, ASCII, Modbus) {5†L6} |
|
Max Hardware Counter |
7 kHz {5†L8} |
|
I/O Expansion Max |
Digital: 110 / Analog: 48 {5†L8-L9} |
|
Operating Temperature |
0 ... +55 °C (Operation) / -40 ... +75 °C (Storage) {pdf:1 ; 10†L21} |
|
Mounting |
DIN Rail (TH35-15 / TH35-7.5 per IEC 60715) {5†L9} |
|
Certifications |
CE, DNV (Det Norske Veritas) {pdf:1 ; 10†L25-L26} |
|
Dimensions |
12x9.3x8.4cm |
|
Weight |
0.34kg |
The ABB 07CT41 1SBP260022R1001 is a compact and scalable Central Unit from the Advant Controller 31 (AC31) series, engineered for reliable distributed automation in demanding environments. Featuring 8 digital inputs and 6 fast transistor outputs, the ABB 07CT41 offers a perfect balance of functionality and space-saving design. It is equipped with an integrated RS232 interface supporting Modbus and ASCII protocols, ensuring smooth connectivity with a variety of field devices and legacy systems. The 1SBP260022R1001 can operate as a standalone logic controller or be expanded with up to 110 digital I/O points, providing a cost-effective solution for modernizing industrial automation systems. With a wide operating temperature range and robust construction, the ABB 07CT41 1SBP260022R1001 delivers exceptional long-term stability, making it an ideal core component for upgrading legacy control cabinets.
Retrofit & Legacy System Upgrades: The ABB 07CT41 is an ideal replacement part for old ABB 07 series PLCs in power plants, water treatment facilities, and general infrastructure upgrades.
Distributed Automation: Serves as a cost-effective remote I/O or logic processor in distributed control systems (DCS) requiring real-time data acquisition.
Small to Medium Machine Control: Perfect for controlling packing machines, labeling equipment, conveyor systems, and printing presses requiring mixed digital I/O count (14 total points).
Smart Low-Voltage Switchgear: Commonly utilized as a control element in low-voltage intelligent switchgear and automatic transfer switch (ATS) cabinets.
Pulse & Counter Monitoring: Can be configured to handle high-speed counting (7 kHz) from encoders and flow meters via its built-in hardware counters.
Space-Saving & Modular Design: High-density design reduces panel space while still allowing external expansion up to 110 digital I/O via the CS31 bus.
Built-in Communication: Onboard RS232 interface eliminates the need for an extra communication module for Modbus/ASCII programming.
Environmental Durability: Designed to operate reliably in temperatures of 0°C to +55°C, suitable for industrial environments with thermal fluctuations.
Integrated Diagnostics: Hardware counters and fast processing ensure precise control over mechanical processes.
Logic & Sequence Control: Functions as a Programmable Logic Controller (PLC) executing user-defined logic for automated machinery processes.
Data Processing & Storage: Manages program logic and user data with consistent accuracy using 34 kB of combined memory architecture.
System Expansion: Acts as a master controller communicating via the CS31 fieldbus to manage additional I/O modules and expand system capacity.
Field Device Interfacing: Provides direct connection for sensors and switches via 8 integrated inputs, while driving actuators such as relays or solenoid valves through 6 transistor outputs.
Real-Time Clock (RTC): Maintains accurate time-stamping for event logging and scheduled control tasks within the automation system.
Q1: What is the power requirement for the ABB 07CT41 1SBP260022R1001?
A: The unit requires a standard 24V DC power supply to operate.
Q2: Is the ABB 07CT41 suitable for high-speed counting applications?
A: Yes, the ABB 07CT41 supports up to 2 high-speed hardware counters capable of reading pulse signals up to 7 kHz from encoders or sensors.
Q3: How do I program the ABB 07CT41 PLC?
A: It features a built-in RS232 port that allows for programming and configuration using standard ABB software suites, supporting ASCII and Modbus protocols.
Q4: Can I expand the I/O capacity of the ABB 07CT41 beyond the built-in 8/6 configuration?
A: Yes. The ABB 07CT41 is a scalable central unit. It supports expansion modules, allowing you to configure up to 110 digital I/O and 48 analog I/O channels for complex automation projects.
Q5: Does the ABB 07CT41 1SBP260022R1001 hold an international marine certificate?
A: Yes, specifically the ABB 07CT41 holds DNV (Det Norske Veritas) certification, making it suitable for marine, offshore, and shipbuilding industrial applications.
