ABB AI880A 3BSE039293R1 High Integrity Analog Input

ABB AI880A 3BSE039293R1 High Integrity Analog Input

Product Name: High Integrity Analog Input

Brand Name: ABB

Model Number: AI880A 3BSE039293R1

Place of Origin: SWEDEN

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

abb ai880a 3bse039293r1 high integrity analog input-1

Overview
Contact Info
Parameter
Introduction
Function
Features
Applications & Use Cases
System Compatibility
Recommended Products

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Contact Info

Sales	Email	Whatsapp
Jim Pei	[email protected]	+86 18020776782

Parameter

Product Name	ABB AI880A 3BSE039293R1 High Integrity Analog Input
Manufacturer	ABB
Product Type	High Integrity Analog Input
Part Number	AI880A 3BSE039293R1
Weight	0.18kg
Estimated shipping dimensions	4.5x11x11.7cm
Place of shipment	Xiamen, China
Country of origin	SWEDEN
Signal specification	0..20 mA, 4..20 mA
Number of channels	8
Signal type	Unipolar single ended
Resolution	12 bit
Input impedance	250 Ω with shunt stick TY801
Max input voltage (non destructive)	11 V d.c
NMRR, 50Hz, 60Hz	> 40 dB
Rated insulation voltage	50 V
Dielectric test voltage	500 V a.c.
Temperature, Operating	0 to +55 °C (+32 to +131 °F)
Temperature, Storage	-40 to +70 °C (-40 to +158 °F)

Introduction

The ABB AI880A (3BSE039293R1) High Integrity Analog Input Module is a safety-oriented industrial signal acquisition module designed for ABB automation and process control systems. It provides reliable and accurate measurement of analog process signals, specifically supporting 0–20 mA and 4–20 mA current inputs commonly used in industrial instrumentation. With 8 input channels and a compact design, the module is intended for high-integrity applications where signal accuracy, stability, and functional safety are critical.

Manufactured by ABB in Sweden, the AI880A is engineered for demanding control environments that require robust performance and dependable signal handling. Its high-integrity design ensures secure data acquisition for safety-related and mission-critical processes. With 12-bit resolution and strong electrical isolation characteristics, the module delivers precise measurement performance while maintaining compliance with industrial safety and reliability requirements.

Function

The AI880A 3BSE039293R1 functions as a high-integrity analog input interface between field transmitters and the control system. It receives standard industrial current loop signals (0–20 mA and 4–20 mA) from sensors such as pressure, temperature, flow, and level transmitters, then converts them into digital values for processing by the controller. This enables accurate real-time monitoring of key process variables in automated systems.

In addition to signal conversion, the module ensures signal integrity through electrical isolation, noise rejection (NMRR > 40 dB at 50/60 Hz), and stable measurement performance across industrial environments. With 250 Ω input impedance (using shunt stick TY801), it supports standardized current loop interfacing. The module is designed to maintain reliable operation in safety-critical applications, ensuring that process data remains accurate and consistent for control, monitoring, and protective system functions.

Features

8-channel high-integrity analog input module.
Supports 0–20 mA and 4–20 mA industrial current loop signals.
12-bit analog-to-digital conversion resolution for accurate measurements.
Unipolar single-ended signal configuration.
Input impedance of 250 Ω (with shunt stick TY801).
Maximum non-destructive input voltage: 11 V DC.
High noise rejection (NMRR > 40 dB at 50/60 Hz).
Rated insulation voltage of 50 V with 500 V AC dielectric test strength.
Compact and lightweight design (0.18 kg).
Wide operating temperature range: 0°C to +55°C.
Storage temperature range: -40°C to +70°C.
Designed for high-integrity and safety-related applications.
Robust electrical isolation for improved signal stability and protection.

Applications & Use Cases

Safety-related process control systems (SIS/DCS environments).
Industrial automation and plant control systems.
Oil and gas production and refining facilities.
Chemical and petrochemical process monitoring.
Power generation and utility control systems.
Water and wastewater treatment plants.
Continuous monitoring of process variables such as pressure, flow, temperature, and level.
Critical instrumentation signal acquisition in hazardous or high-reliability environments.
Process optimization and real-time control applications.
Redundant or high-availability automation architectures.

System Compatibility

The ABB AI880A 3BSE039293R1 is designed for integration within ABB industrial automation platforms and is compatible with:

ABB AC 800M control systems and related architectures.
ABB S800 I/O systems.
Standard 4–20 mA and 0–20 mA field transmitters.
Industrial process instrumentation (pressure, flow, temperature, level sensors).
Safety Instrumented Systems (SIS) and high-integrity control applications.
ABB distributed control systems (DCS).
Existing ABB I/O racks supporting S800 series modules.
Process automation and safety monitoring networks.

Its high-integrity design, strong electrical isolation, and precise analog measurement capability make the AI880A a reliable choice for safety-critical and high-performance industrial process control applications.
