Product Name: AC Servo Motor
Brand Name: ABB
Model Number: BSM80C-275AFX
Place of Origin: SWEDEN
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Minimum Order Quantity |
1 Piece |
Price |
Contact for Jim |
Packaging Details |
Original new Factory Sealed |
Delivery Time |
3–7 Days |
Payment Terms |
T/T |
Shipping Method |
DHL / FedEx / UPS / TNT |
Supply Ability |
In stock |
|
Sales |
|
|
|
Jim Pei |
| Product Name | ABB BSM80C-275AFX AC Servo Motor |
| Manufacturer | ABB |
| Product Type | AC Servo Motor |
| Part Number | BSM80C-275AFX |
| Weight | 4.04 kg |
| Estimated shipping dimensions | 12x8.8x20cm |
| Place of shipment | Xiamen, China |
| Country of origin | SWEDEN |
| Motor Type | Brushless Servo Motor |
| Series | BSM C-Series |
| Feedback Device | Encoder equipped |
| Rated Speed | 4000 RPM |
| Maximum Speed | 7000 RPM |
| Continuous Current | 0.24 A |
| Peak Current | 8.25 A |
| Rated Bus Voltage | 300 VDC |
| Output Power | 0.92 kW |
| Shaft Rotation | Reversible |
| Insulation Class | Class F |
The ABB BSM80C-275AFX AC Servo Motor is a high-performance brushless servo motor designed for precision motion control in industrial automation systems. Belonging to ABB’s BSM C-Series, it is engineered to deliver smooth, accurate, and dynamic rotational motion for applications requiring high positioning accuracy and fast response. With a compact frame size and integrated encoder feedback, the motor is well-suited for servo-driven systems where precise speed and torque control are essential.
Manufactured in Sweden and widely used in global automation markets, the BSM80C-275AFX combines robust mechanical construction with advanced electromagnetic design. It operates at a rated speed of 4000 RPM with a maximum speed of up to 7000 RPM, delivering up to 0.92 kW of output power. Its lightweight design (4.04 kg) and reversible shaft rotation further enhance installation flexibility in a wide range of motion control systems.
The BSM80C-275AFX functions as a precision electromechanical actuator that converts electrical energy into controlled rotational motion. As a brushless servo motor, it works in conjunction with a servo drive system to regulate speed, torque, and position based on real-time feedback from its integrated encoder. This closed-loop control ensures highly accurate motion performance even under varying load conditions.
In operation, the motor receives control signals from a servo drive powered by a 300 VDC rated bus voltage. It then generates controlled mechanical output to drive mechanical systems such as conveyors, robotic arms, CNC axes, and other motion platforms. The encoder continuously provides feedback to the controller, enabling precise adjustments for positioning accuracy, speed stability, and dynamic response in demanding automation environments.
The ABB BSM80C-275AFX AC Servo Motor is designed for integration with ABB and compatible servo drive systems and motion control platforms, including:
Its high-speed performance, encoder-based precision control, and robust brushless design make the BSM80C-275AFX an ideal solution for demanding motion control applications requiring accuracy, reliability, and dynamic responsiveness.
