Product Name: Digital Output Module
Brand Name: ABB
Model Number: DSDO120 57160001-AK
Place of Origin: SWEDEN
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
The ABB DSDO120 57160001-AK Digital Output Module is a reliable industrial output module designed for use in automation and control systems. It provides digital output signals for controlling field devices such as relays, contactors, solenoid valves, alarms, and indicator lamps. Operating with an output voltage range of 24–48 VDC and a maximum output current of 1 A, the module ensures stable and efficient signal transmission. Featuring Profinet communication, IP20 protection, and compliance with UL/cUL/cCSA standards, the DSDO120 is suitable for demanding industrial applications requiring dependable output control and system integration.
|
Sales: |
Email: |
Whatsapp: |
|
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
| Product Name | ABB DSDO120 57160001-AK Digital Output Module |
| Manufacturer | ABB |
| Product Type | Digital Output Module |
| Part Number | DSDO120 57160001-AK |
| Weight | 0.44kg |
| Estimated shipping dimensions | 2x25.3x24.3cm |
| Place of shipment | Xiamen, China |
| Country of origin | SWEDEN |
| Output Voltage | 24–48 VDC |
| Output Current | 1 A |
| Signal Type | Digital Output |
| Application | Industrial Automation and Control Systems |
| Installation Type | System I/O Module |
| Mounting Type | Panel |
| Enclosure Type | IP20 |
| Temperature Range | -20°C to +55°C |
| Environmental Compliance | UL/cUL/cCSA |
| Communication Interface | Profinet |
Reliable Output Performance
The DSDO120 provides stable digital output signals with up to 1 A output current, ensuring dependable operation of connected field devices.
Wide Voltage Compatibility
Supporting 24–48 VDC output, the DSDO120 offers greater flexibility for integration with various industrial control equipment.
Profinet Communication Capability
The integrated Profinet interface enables efficient communication and seamless integration into modern industrial Ethernet networks.
Industrial-Grade Design
Designed for continuous industrial operation, the DSDO120 delivers high reliability and long service life in demanding environments.
Certified Safety and Compliance
Compliance with UL, cUL, and cCSA standards ensures that the DSDO120 meets recognized industrial safety and quality requirements.
Easy System Integration
As part of ABB's automation portfolio, the DSDO120 can be easily integrated into existing ABB control architectures, reducing installation and commissioning time.
The ABB DSDO120 57160001-AK is designed for industrial control cabinet installation and operates reliably within a temperature range of -20°C to +55°C. The module features an IP20 enclosure rating, providing protection against accidental contact with internal components when installed in a suitable enclosure. It is intended for use in clean, dry industrial environments and complies with UL/cUL/cCSA standards. For optimal performance, the DSDO120 should be mounted on a panel in a properly ventilated control cabinet and protected from excessive moisture, dust, vibration, and electromagnetic interference.
Q1: What protection level does ABB DSDO120 57160001-AK provide?
The ABB DSDO120 57160001-AK has an IP20 enclosure rating, suitable for installation inside protected industrial control cabinets.
Q2: What output voltage does ABB DSDO120 57160001-AK support?
The ABB DSDO120 57160001-AK supports output voltages ranging from 24 VDC to 48 VDC, making it suitable for a wide range of industrial applications.
Q3: What is the maximum output current of ABB DSDO120 57160001-AK?
The ABB DSDO120 57160001-AK provides a maximum output current of 1 A, allowing it to reliably drive various industrial field devices.
Q4: Does ABB DSDO120 57160001-AK support communication interfaces?
Yes, the ABB DSDO120 57160001-AK features a Profinet communication interface for seamless integration into industrial Ethernet automation systems.
Q5: What devices can ABB DSDO120 57160001-AK control?
The ABB DSDO120 57160001-AK can control relays, contactors, solenoid valves, motor starters, indicator lamps, and alarm devices used in industrial automation systems.
