Product Name: Pulse Counter Board
Brand Name: ABB
Model Number: DSDP160 57160001-KG
Place of Origin: Sweden
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
The ABB DSDP160 57160001-KG Pulse Counter Board is an industrial pulse processing module designed for high-speed signal counting and monitoring applications. It is used in automation systems to accurately detect, count, and process pulse signals from devices such as encoders, flow meters, and speed sensors. With a maximum pulse frequency of 10 kHz, a 50 µs minimum pulse width, and stable 24V DC operation, the DSDP160 ensures reliable performance in industrial control environments requiring precise pulse measurement.
|
Sales: |
Email: |
Whatsapp: |
|
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
| Product Name | ABB DSDP160 57160001-KG Pulse Counter Board |
| Manufacturer | ABB |
| Product Type | Pulse Counter Board |
| Part Number | DSDP160 57160001-KG |
| Weight | 0.38 kg |
| Estimated shipping dimensions | 2x25x24.5cm |
| Place of shipment | Xiamen, China |
| Country of origin | SWEDEN |
| Input voltage range | 20V to 30V DC |
| Approximately | 10-15W |
| Current Consumption | 0.5 A (typical) at 24V DC |
| Maximum pulse frequency | 10 kHz |
| Minimum pulse width | 50 µs |
High-Speed Pulse Handling Capability
The DSDP160 supports up to 10 kHz pulse frequency, making it more suitable for fast industrial signal applications than many standard counter boards.
Improved Signal Detection Accuracy
With a minimum pulse width of 50 µs, it ensures more precise pulse recognition and reduces the risk of missed or distorted signals.
Stable Industrial Operation
Designed for 20–30V DC input, the module maintains consistent performance under typical industrial power conditions.
Reliable Measurement Performance
It delivers accurate pulse counting for applications such as flow measurement, speed monitoring, and position tracking.
Optimized Power Efficiency
With a moderate power consumption range of 10–15W, it balances performance with energy efficiency in continuous operation environments.
ABB System Integration
Fully compatible with ABB automation platforms, ensuring stable communication and reduced integration complexity.
The ABB DSDP160 57160001-KG is designed for installation inside industrial control cabinets and operates on a 20–30V DC power supply. It is suitable for environments where temperature, humidity, and electromagnetic conditions are controlled according to standard industrial automation requirements. The module should be installed in a well-ventilated enclosure and protected from excessive dust, moisture, vibration, and electrical noise to ensure accurate pulse detection and long-term reliability.
Q1: What is ABB DSDP160 57160001-KG used for?
The DSDP160 57160001-KG is used for counting and processing high-speed pulse signals in industrial automation systems.
Q2: What is the maximum pulse frequency of DSDP160 57160001-KG?
The DSDP160 57160001-KG supports a maximum pulse frequency of 10 kHz.
Q3: What is the minimum pulse width supported by DSDP160 57160001-KG?
The DSDP160 57160001-KG supports a minimum pulse width of 50 µs for accurate signal detection.
Q4: What is the operating voltage of ABB DSDP160 57160001-KG?
The ABB DSDP160 57160001-KG operates within a 20–30V DC voltage range.
Q5: What is the typical power consumption of DSDP160 57160001-KG?
The DSDP160 57160001-KG consumes approximately 10–15W with a typical current of 0.5A at 24V DC.
Q6: What devices can DSDP160 57160001-KG connect to?
The DSDP160 57160001-KG can connect to encoders, flow meters, speed sensors, and other pulse-generating industrial devices.
